BT4000
SMALL FLAT SCREEN FLOOR STAND
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Floor Base
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Optional Accessories..........................................................................................................................9
Typical Installations................................................................................................................................10
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
INSTALLATION TOOLS REQUIRED
B-TECH AUDIO VIDEO MOUNTS
FEATURES
● Designed for flat screens up to
23" (58cm) / 15kg (33lbs)
● Can be used free standing or bolted to the floor
● Supplied with optional rubber feet
● Can be used with BT7510, BT7511, BT7521,
BT7522, BT7320, BT7505, BT7532 or BT7533
flat screen interface mounts
*
Support column and flat screen interface kit
sold separately
CONTENTS
Hex Key
(Supplied)
www.btechavmounts.com
Advertisement
Related Manuals for B-Tech BT4000
Summary of Contents for B-Tech BT4000
-
Page 1: Table Of Contents
Support column and flat screen interface kit sold separately CONTENTS Installation Safety Notes........................2 Parts List.............................4 Installation Instructions........................6 Optional Accessories..........................9 Typical Installations..........................10 Product Dimensions..........................11 B-Tech Contact Details........................12 INSTALLATION TOOLS REQUIRED Hex Key (Supplied) B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com... -
Page 2: Installation Safety Notes
Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. - Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.
-
Page 4: Parts List
BT4000 PARTS LIST Ø60mm pole (BT4005, BT4011, BT4015 and BT4020) are sold separately Suitable for loads up to 15kg (33lbs) - Page 5 PART NAME SMALL FLOOR BASE M16 x 50mm HEX SCREW POLE TRIM RING PLASTIC HOLE CAP RUBBER FOOT POLE END CAP 10mm HEX KEY (FOR PART 2) PLEASE KEEP THIS FOR FUTURE REFERENCE...
-
Page 6: Installation Instructions
Optional: Slide trim ring onto the bottom of the pole. POLE LENGTHS BASE PART SIZE 0.5M 1.1M 1.5M 2.0M SMALL BT4000 MEDIUM BT4001 LARGE BT4002 DESCRIPTION Ø60mm pole SAFE FOR FREE STANDING (BT4005, BT4011, BT4015 and BT4020) MUST BE BOLTED TO THE FLOOR... - Page 7 Fix the pole to the floor base. Ø60mm pole (BT4005, BT4011, BT4015 and BT4020) are sold separately 60mm POLE...
- Page 8 Follow instructions on chosen interface (BT7510, BT7511, BT7521, BT7522, BT7320, BT7505, BT7532 or BT7533) then fix to collar and secure mount. Continue with step 4. Attach the pole end cap (part 6) and plastic hole caps (parts 4) to stand. BT7521 FLAT SCREEN...
-
Page 9: Optional Accessories
OPTIONAL ACCESSORIES B-Tech AV Component Shelves BT7164 BT7162 BT7161 BT7161 BT7161 BT7162 BT4000... -
Page 10: Typical Installations
TYPICAL INSTALLATIONS BT7320 BT7260 BT7260 BT7521 60mm 60mm POLE POLE BT7260 BT7161 BT7521 BT7162 BT4000 BT4000 BT7505 BT7260 BT7260 BT7511 60mm 60mm POLE POLE BT7161 BT7161 BT7162 BT7162 BT4000 BT4000... -
Page 11: Product Dimensions
BT4000 PRODUCT DIMENSIONS 575mm 22.6" 12mm 270mm .5" 10.6" .2" 110mm 4.3" 445mm 17.5" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT. -
Page 12: B-Tech Contact Details
©2010 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech and Better By Design are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
