Risk of damage of the product
Only use the specified type of battery /
rechargeable battery!
When inserting ensure the correct
polarity! This is shown inside the battery
compartment!
Clean the contacts on the battery and
in the battery compartment before
inserting!
Remove exhausted batteries /
rechargeable batteries from the product
immediately.
˜ Before start of operation
˜ Insert / replace battery
Tip: Flashing numbers indicate a discharged / flat battery.
Tip: When changing the battery, the LCD display 5 may
experience faults. Remove the battery and insert it again after
waiting more then 30 seconds.
Push open the lid to the battery compartment 8 (see Fig. B).
Remove the old battery.
Insert the new battery into the battery compartment and
ensure correct polarity (+ and –). Make sure that the plus
terminal points outwards.
Push the lid to the battery compartment 8 shut again (see
Fig. B).
˜ Preparing the calliper
Loosen the locking screw 4 so that you can move the
calliper.
Clean all measuring surfaces 1 and the calliper rod with a
dry cloth. Otherwise, faulty measuring results may occur due
to, for example, humidity.
Check that all keys, switches and the LCD display 5 work
correctly.
˜ Starting up the device
˜ Using the calliper
Loosen the locking screw 4 by turning it anti-clockwise.
Push the external measuring jaws 11 and the internal
measuring jaws 2 together.
Switch the LCD display 5 on by pressing the ON / OFF key 10.
Press the inch / mm key 3 to set the unit of measurement
(inch or mm) you wish to use. Either "mm" or "in" will
appear to the right of the figures in the LCD display 5 .
Press the key to obtain the zero setting (ZERO) 9 in order
to reset the LCD display 5 to zero.
Measuring an object from the outside:
Move the external measuring jaws 11 apart by turning the
handwheel 7 outwards anti-clockwise. Place the external
measuring jaws 11 against the object to be measured.
