Summary of Contents for Gefen VDL-1000
- Page 1 VDL•1000 U S E R M A N U A L www.gefen.com...
- Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. VDL•1000 is a trademark of Gefen Inc. Macintosh is a trademark of Apple Computer Inc.
- Page 3 INTRODUCTION OPERATION NOTES INSTALLATION INSTRUCTIONS HOW TO ADJUST THE PICTURE CAT5 WIRING DIAGRAM WIRING DIAGRAM SPECIFICATIONS WARRANTY TABLE OF CONTENTS...
- Page 4 INTRODUCTION Thank you for purchasing the new ex•tend•it VDL•1000 by Gefen, Inc. The VDL•1000 improves the quality of picture transmission over CAT5, CAT5e, or CAT6 UTP or STP cables and may be used with any extender. CAT5/6 cable has been optimized for network data transmission and has four separate twisted pairs each with a different number of turns per unit length to reduce crosstalk between pairs.
- Page 5 VDL•1000 FRONT PANEL LAYOUT...
- Page 6 VDL•1000 BACK PANEL LAYOUT...
- Page 7 TIMING DETAILS...
- Page 8 SPECIFICATIONS Video Amplifi er Bandwidth ... 350 MHz Actual Bandwidth ... 120 MHz Input Video Signal ... 1.2 Volts p-p Video In ... HD-15 Video out ... HD-15 Power Consumption ... 1 Amp Power Supply ... 5VDC (External) Dimensions ... 1.9”H x 1.6”W x 3.5”D Shipping Weight ...
- Page 9 WIRING DIAGRAM...
- Page 10 If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
