Gefen HD-1000 User Manual

Hd-1000 extender

Advertisement

HD-1000
Extender
Model # EXT-HD-1000
U S E R
M A N U A L
www.gefen.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD-1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gefen HD-1000

  • Page 1 HD-1000 Extender Model # EXT-HD-1000 U S E R M A N U A L www.gefen.com...
  • Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. HD-1000 is a trademark of Gefen Inc. HDMI is a trademark of HDMI.org ©...
  • Page 3: Table Of Contents

    Introduction / Operation Notes Features Sender Panel Descriptions Receiver Panel Descriptions Connecting and Operating the HD-1000 Network Cable Wiring Diagram Specifi cations Warranty TABLE OF CONTENTS...
  • Page 4: Introduction / Operation Notes

    The Gefen HD-1000 allows an HDMI video signal to be extended up to 330 feet (1640 w/o HDCP) using multi-mode LC-LC fi ber optic cable. Fiber Optics technology allows the HD-1000 to carry video signals over long distances that are not possible with other technologies. Fiber Optic cables are immune to video signal corruption from electromagnetic interference (EMI), ensuring a crystal clear picture.
  • Page 5: Features

    Features • Extends high defi nition HDMI compliant devices up to 330 feet (100 meters) • Uses a 4 strand multi mode LC-LC fi ber optic cable for HDMI and a CAT5e cable for DDC/control signals • Extends range of HDMI by equalizing signals •...
  • Page 6: Sender Panel Descriptions

    SENDER PANEL DESCRIPTIONS Front Panel Power LED Indicator Status LED Indicator Back Panel HDMI Input RJ-45 Port Port Fiber Optic LC-LC Terminals 5V DC Power Input...
  • Page 7: Receiver Panel Descriptions

    RECEIVER PANEL DESCRIPTIONS Power LED Indicator Status LED Indicator RJ-45 Port 5V DC Power Input Front Panel Back Panel HDMI Input Port Fiber Optic LC-LC Terminals...
  • Page 8: Connecting And Operating The Hd-1000

    CONNECTING AND OPERATING THE HD-1000 How To Connect The HD-1000 Connect the HDMI source to the HD-1000 sender unit using the supplied HDMI cable. Connect a user supplied CAT-5, CAT-5e or CAT-6 cable to the sender unit. Connect four user supplied multi-mode LC terminated fi ber optic cables into HD-1000 sender unit.
  • Page 9: Network Cable Wiring Diagram

    Gefen has specifi cally engineered their products to work with the TIA/EIA-568-B specifi cation. Please adhere to the table below when fi eld terminating cable for use with Gefen products. Failure to do so may produce unexpected results and reduced performance.
