Installing The Network Card - Gateway ADC-220 User Manual

Digital audio (coaxial)
■
Connect one end of a digital coaxial cable (not included) to the
COAXIAL
to the coaxial digital audio jack of your amplifier.
Digital audio (optical)
■
Connect one end of an optical cable (not included) to the
DIGITAL AUDIO
end to the optical digital audio jack of your amplifier.
Tips & Tricks

Installing the network card

Do not plug in the player's power cord or press the POWER button on the front
until you have installed the network card.
To install the network card:
1
Make sure that the player is turned off.
2
Insert your network PC Card (one may have been provided with your
player) into the
that the network card is pressed all the way in.
Network card slot
jack on the back of the player, then connect the other end
jack on the back of the player, then connect the other
If you are using a digital audio connection (COAXIAL or
OPTICAL DIGITAL AUDIO), you must set the audio output
format to match the digital decoding capabilities of your
amplifier. For more information, see "Setting up digital
audio" on page 39.
slot in the back of the player. Make sure
NETWORK CARD
www.gateway.com
Connecting the player
OPTICAL
17
