Specifications
Video
Video Out
1.0Vp-p 75
jack (1)
S-Video Out
Y: 1.0Vp-p 75
(separate Y and C
C: 0.286Vp-p 75
signal output)
Component Video Out
Y: 1.0Vp-p 75
(progressive/
Cb: 0.7Vp-p 75
interlace scan modes)
Cr: 0.7Vp-p 75
Supported video and
MPEG1: <3 Mbps
image formats
MPEG2: <3 Mbps
JPEG/JPG: >25 Kbps
Audio
Analog Out
1.85V(rms)/10k
Coaxial Out
0.5Vp-p 75
Ω
sync, negative polarity, RCA pin
Ω
sync, negative polarity
Ω
Ω
Ω
Ω
Ω
RCA L/R pin jack (1)
Ω
; RCA pin jack (1)
A
87
