Back - Gateway ADC-220 User Manual

Back

Network card slot
Network card slot
Insert a network PC Card into this slot.
Audio jacks
5.1 channel (surround sound)
5.1 channel (surround
sound)
2 channel (stereo)
Coaxial (digital audio)
Optical digital audio
Audio jacks
Video jacks
2 channel (stereo)
Connect to the analog audio inputs of a 5.1-channel amplifier.
Connect to the left/right analog audio inputs of a TV, stereo, or
2-channel amplifier.
Connect to the coaxial digital audio input of a 5.1-channel amplifier.
Connect to the optical digital audio input of a 5.1-channel amplifier.
www.gateway.com
Coaxial (digital Optical digital
audio) audio
Player overview
5
