2 ATS Series Installation Manual

Table of Contents

Installation Instructions
1. Installation Safety Warnings!
2. Before you Begin
3. Tools Required
4. Kit Contents
5. Position
6. Fit the Opener
7. Bracket Position
7.1 Wall Bracket Position:
7.2 Mounting The Wall Bracket:
7.3 Attach The Rail To The Wall Bracket
8. Perforated Angle
9. Mounting Brackets and Arms
9.1 Mounting The Door Bracket:
9.2 Attaching the Arms
10. Safety Beam Kit
(ATS-3 Only)
10.1 Assemble the Mounting Bracket
10.2 Mounting the Bracket
10.3 Connect the Safety Beams
11. Specifications
12. Setting Limits
12.1 Set Limit Positions and adjust drive speed: 10
12.2 Clearing the Door Limit Positions
12.3 Re-profiling the Door
12.4 Controller memory reset
13. Safety Testing
13.1 Test the Close Cycle
13.2 Testing the Open Cycle
13.3 Test the Manual Door Operation
14. Auto-Close
WARNING! IMPORTANT SAFETY INSTRUCTIONS
FOLLOW ALL INSTRUCTIONS SINCE INCORRECT INSTALLATION CAN LEAD TO SEVERE INJURY.
• before installing the drive, remove all unnecessary ropes or chains and disable any equipment, such as locks, not needed for
powered operation;
• before installing the drive, check that the door is in good mechanical condition, correctly balanced and opens and closes
properly;
• install the actuating member for the manual release at a height less than 1,8 m;
• install any fixed control at a height of at least 1,5 m and within sight of the door but away from moving parts;
• permanently fix the labels warning against entrapment in a prominent place or near any fixed controls;
• permanently fix the label concerning the manual release adjacent to its actuating member;
• after installation, ensure that the mechanism is properly adjusted and that the drive reverses when the door contacts a 40
mm high object placed on the floor.
• necessary information for the safe handling of a drive weighing more than 20 kg. This information shall describe how to use
the handling means, such as hooks and ropes;
• the drive must not be used with a door incorporating a wicket door (unless the drive cannot be operated with the wicket door
open);
• after installation, ensure that parts of the door do not extend over public footpaths or roads.
• vertical doors and gates need an anti-drop feature or device;
• information if a hazardous part of the drive is intended to be installed at a height of at least 2.5 m above floor level or other
access level;
• except for horizontally moving pedestrian doors, ensure that entrapment due to the opening movement of the driven part
is avoided
3
15. Coding a Transmitter
15.1 Storing the Transmitter Code
4
15.2 Installation of the Wall Mounted Transmitter 14
4
15.5 Remotely Coding Transmitters
5
15.3 Erasing All Transmitter Codes
15.4 Vacation Mode
5
16. Smart Phone Control
6
6
Home Owner Instructions
6
6
17. Home Owner Safety Warnings!
6
18. Opener Safety & Security
7
18.1 Your Door CAN NOT be used when:
7
18.2 Your Door CAN be used when:
18.3 To Disengage the Opener:
7
18.4 To Re-Engage the Opener:
7
19. Operating your Opener
8
8
20. User Operating Controls
8
21. Troubleshooting
8
22. After Installation Care
9
22.2 Battery Replacement
10
22.3 Battery Disposal
22.4 Warranty
11
23. Appendix
11
A - Status Indication during Operating Mode.
11
B - Adjustment Mode Instructions
12
C - Adjusting Force Margins
12
D - Battery Functions
12
E - Setting limits via Transmitter
12
F - Setting the PET Mode position
13
G - Setting up Tilt Door
14
14
14
14
14
15
(ATS-3 Only)
16
17
17
17
17
17
17
18
19
21
22
22
22
23
23
24
24
25
25
26
26
