- Page 1 ANI-23TCDTX/RX Analog Stereo Audio & RS-232 over CAT5e/6/7 Extenders TRANSMITTER RECEIVER A-NeuVideo.com Frisco, Texas 75034 (469) 277-7606 AUDIO / VIDEO MANUFACTURER...
- Page 2 SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.
- Page 3 INTRODUCTION weight to be placed upon it or any person walk on it. The ANI-23TCDTX/RX Analog Stereo Audio and RS-232 over • To protect the unit from overheating, do not block any vents or CAT5e/6/7 extenders are designed to extend analog stereo audio openings in the unit housing that provide ventilation and allow for over a single run of CAT5e/6/7 cable up to ~985ft/300M.
- Page 4 NEUVIDEO FEATURES & SPECIFICATIONS FEATURES • Supports Analog stereo audio and RS-232 extension over a signal CAT5e/6/7 cable up to ~985ft/300M • Transmitter supports Power over Cable (PoC) to the Receiver unit • Bi-directional RS-232 control Specifications TRANSMITTER • Input Ports: •...
- Page 5 NEUVIDEO Operation controls & Functions Front Panel L/R IN: Connect to source equipment such as DVD/Blu-ray player, Set-Top Box or game console for audio input signal routing. Both the Transmitter and Receiver have L/R in and the audio signal will send out through AUDIO-CAT to the connected device’s L/R out. L/R OUT: Connect to active speakers or AV amplifiers with L/R cable for audio output.
- Page 6 NEUVIDEO RS-232 Pin Definition RS-232 Pin Definition ASSIGNMENT ASSIGNMENT Baud Rate: 110 ~ 921600 Data Bit: 8 bits Parity: None Stop Bit: 1 bit Flow Control: None...
- Page 7 NEUVIDEO CONNECTION DIAGRAM CONNECTION DIAGRAM...
- Page 8 BY, THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
