- Page 1 ANI-HDB70 HDMI Extender over HDBaseT ™ A-NeuVideo.com Frisco, Texas 75034 (317) 456-2461 V2.4 AUDIO / VIDEO MANUFACTURER...
-
Page 2: Safety Information
SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit. - Page 3 HDMI signal, so you can control the source device or the display. sufficient space for air to circulate around the unit. The ANI-HDB70 operates at 1080p up to 230 ft (70M) using CAT5e or better. The greatest feature is the PoH (Power over HDBaseT ™...
-
Page 4: Features And Specifications
• Full 3D pass through • High EMI rejection for compatibility even in challenging installations • Supports all embedded audio signals including Dolby TrueHD and DTS-HD Master Audio • The ANI-HDB70 is not compatible with EZ-45 connectors Specifications • Frequency Bandwidth: 2.97Gbps • HDMI Transmitter Input/Output Ports:... - Page 5 NEUVIDEO Operation controls and Functions Transmitter DC IN: Plug the 24V DC power supply into the unit. IR OUT: IR Transmitter. IR IN: IR Receiver. HDMI IN: HDMI Input port. HDMI SIgNAl OUT: CAT5e/6/7 RJ-45 IEEE-568B lINK lED: Illuminates when the Transmitter unit and Receiver unit has a valid LAN connection. Receiver DC IN: Plug the 24V DC power supply into the unit.
- Page 6 NEUVIDEO Application Example / IR EXAMPLE EXAMPLE IR EMITTERS 56khz...
- Page 7 THIS PAGE IS INTENTIONALLY LEFT BLANK.
-
Page 8: Terms And Conditions Of Use
BY, THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
