- Page 1 ANI-605XPLBD Transmitter & Receiver HDMI to CAT5e/6/7 Extender ANI-605XPLBDT ANI-605XPLBDR A-NeuVideo.com Frisco, Texas 75034 (317) 456-2461 V1.0 AUDIO / VIDEO MANUFACTURER...
- Page 2 SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.
-
Page 3: Table Of Contents
NEUVIDEO TABLE OF CONTENTS CONTENTS INTRODUCTION & CONTENTS ...........1 SAFETY PRECAUTIONS FEATURES ..................2 Please read all instructions before attempting to unpack, install or SPECIFICATIONS ................ 2 operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this OPERATION CONTROLS &... -
Page 4: Features
NEUVIDEO FEATURES & SPECIFICATIONS FEATURES • Compatible with HDCP and DVI • Supports HDMI 3D and 4K2K features • Supports HDBaseT-Lite™ Technology • Supports HD resolutions up to 1080p@60Hz/36-bit • Supports distance up to 196 ft/60M through CAT5e/6/7 cable • Supports bidirectional IR and PoC •... -
Page 5: Operation Controls & Functions
NEUVIDEO OPERATION CONTROLS & FUNCTIONS Transmitter Front & Rear Panels DC 24V: Plug the 24V DC power supply into the unit and connect the adaptor to an AC outlet. Only (1) side of device requires power supply when both Transmitter and Receiver obtain PoC function. LINK LED: This LED will illuminate when the devices are connected with a CAT5e/6/7 cable from the Receiver side. -
Page 6: Ir Pin Assignment
NEUVIDEO OPERATION CONTROLS & FUNCTIONS IR Pin Assignment IR Blaster Power 5V IR Blaster Signal IR Receiver IR Signal Power 5V Grounding D-Sub 9-Pin Definitions DEFINITIONS DEFINITIONS TxD/RxD RxD/TxD... -
Page 7: Connection Diagram
NEUVIDEO CONNECTION DIAGRAM CONNECTION DIAGRAM... - Page 8 BY, THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
