- Page 1 ANI-FIBER-F02P 4K Fiber Optic HDMI Extender - 3300 FT/1000M - 4K@60Hz w/ IR, RS-232, HDMI 2.0 Support AUDIO / VIDEO MANUFACTURER A-NeuVideo.com Frisco, Texas 75036...
- Page 2 SAFETY INFORMATION 1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. 2. Follow all instructions printed on unit chassis for proper operation. 3.
- Page 3 NEUVIDEO SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. •...
- Page 4 Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton: • ANI-FIBER-F02P18Gbps HDMI over Optical Fiber Extender (Transmitter) • ANI-FIBER-F02P 18Gbps HDMI over Optical Fiber Extender (Receiver) • SFP-BL35T1-02DC Transmitter • SFP-BL531T-02DC Receiver •...
- Page 5 FEATURES • HDMI 2.0b, HDCP 2.2 and DVI 1.0 compliant • Supports 18Gbps video bandwidth • Video resolution up to 4K2K@50/60Hz 4:4:4 • HDMI audio formats: LPCM2/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD •...
- Page 6 SPECIFICATIONS • HDMI Compliance: HDMI 2.0b • HDCP Compliance: HDCP 2.2 • Video Bandwidth: 18Gbps • Video Resolution: 480i ~1080p50/60Hz, 4K2K@24/30Hz, 4K2K@60Hz • Color Space: RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0 • Color Depth: 8/10/12-bit (1080P60Hz) / 8-bit (4K60Hz) •...
- Page 7 OPERATION CONTROLS AND FUNCTIONS Transmitter Panel q POWER LED: The power indicator is always on when the Receiver is powered on. w FIBER LED: The optical fiber connection indicator is always on when the Transmitter and Receiver establish a normal optical fiber signal connection. e HDMI LED: IN: The HDMI signal input indicator is always on when there is signal input on the HDMI IN port.
- Page 8 OPERATION CONTROLS AND FUNCTIONS d HDMI IN: HDMI signal input port, connect to HDMI source device such as DVD or PC with an HDMI cable. f LINE IN: Audio signal input port, connect to audio source device such as MP3. g RS-232: RS-232 signal pass-through port for transmitting RS-232 command signals between the Transmitter and Receiver.
- Page 9 OPERATION CONTROLS AND FUNCTIONS Receiver Panel q POWER LED: The power indicator is always on when the Receiver is powered on. w FIBER LED: The optical fiber connection indicator is always on when the Transmitter and Receiver establish a normal optical fiber signal connection. e HDMI LED: The HDMI signal output indicator is always on when the HDMI OUT port of the Receiver outputs signals to the HDMI display device.
- Page 10 IR Pin Definition IR Receiver and Blaster pin’s definition as below: Optical Fiber Module (INCLUDED) q SFP-BL35T1-02DC: is the optical fiber module for the Transmitter. w SFP-BL531T-02DC: is the optical fiber module of the Receiver. Connect using a single fiber cable. Interface: LC Simplex to LC Simplex...
- Page 11 CONNECTION DIAGRAM The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
- Page 12 THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
