- Page 1 ANI-0104VC VGA CAT5 Extender 1x4 Splitter with Audio INSTRUCTION MANUAL A-NeuVideo.com | Frisco, Texas 75034 (317) 456-2461 V.1.2...
-
Page 2: Safety Information
SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fi re, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit. - Page 3 TABLE OF CONTENTS CONTENTS SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or Introduction ................1 operate this equipment and before connecting the power supply. Package Contents .............. 1 Please keep the following in mind as you unpack and install this equipment: Features ................
- Page 4 FEATURES & SPECIFICATIONS FEATURES This VGA Splitter has many features that enable it to perform in a superior manner. Among those features you will fi nd: • Extends VGA video and stereo audio signal max up to ~1000 ft. / 300m over one CAT5 cable. •...
-
Page 5: Panel Descriptions
PANEL DESCRIPTIONS SENDER RECEIVER... -
Page 6: Connection And Operation
CONNECTION AND OPERATION Connect the single VGA source to the main VGA input using a piece of VGA cable. Connect VGA output of the Sender to a local display and Audio output of the Sender to a local Sounder Connect Sender and each Receiver using a piece of CAT5e/6/7, UTP or STP cable. Connect VGA outputs of Receivers to remote displays and Audio output of Receivers to remote sounders. - Page 7 BY, THROUGH OR UNDER A-NEUVIDEO, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-Neuvideo, Inc. at the return address set forth on the Product’s packing label at your expense.
