- Page 1 ANI-5PLAY HDMI + LAN Extender PoH CAT5e/CAT6 HDBaseT ™ A-NeuVideo.com Frisco, Texas 75034 (317) 456-2461 AUDIO / VIDEO MANUFACTURER...
-
Page 2: Safety Information
SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit. -
Page 3: Table Of Contents
™ to keep current the information contained in this document. only one power supply to provide power to both the Transmitter and the Receiver. The ANI-5PLAY also supports 4K2K! This product ™ We reserve the right to make improvements to this document and/ has a 3 year warranty. -
Page 4: Features
NEUVIDEO FEATURES & SPECIFICATIONS FEATURES • PoH (Power over HDBaseT ) function supports, either the TX or the RX, powered with the 24V@1A power supply, the other does ™ not need power from the DC jack. PoH power consumption is less than 10W •... -
Page 5: Utp Cable Termination
NEUVIDEO UTP CABLE TERMINATION UTP cable termination The extender uses a UTP cable termination following IEEE-568A and IEEE-568B standards. CABLE LENGTH RESOLUTION CAT6 230 ft/70M CAT6 328 ft/100M 1080p CAT5e 131 ft/40M CAT5e 328 ft/100M 1080p Direct Interconnection Method Cross Interconnection Method... -
Page 6: Operation Controls & Functions
NEUVIDEO OPERATION CONTROLS AND FUNCTIONS Transmitter INPUT LED: Input status indicating lamp. This red LED illuminates when the HDMI signal is plugged in. HDMI IN: HDMI input port. This slot is where you connect the HDMI source. ETHERNET: This slot provides internet signal from the receiver or to the receiver. RS-232: Phoenix jack provides Serial port control from the receiver or to the receiver. -
Page 7: Receiver
NEUVIDEO OPERATION CONTROLS AND FUNCTIONS RECEIVER OUTPUT LED: Output status indicating lamp. This red LED illuminates when the TV is connected to a HDMI cable. HDMI OUT: HDMI output port. This slot is where you connect the HDTV or monitor with a HDMI cable. ETHERNET: This slot provides internet signal from the transmitter or to the transmitter. -
Page 8: Descriptions
NEUVIDEO Descriptions Description 1 PoH (Power over HDBaseT ) Application Example. ™ Description 2 Bi-directional Infrared Control Application Example. - Page 9 NEUVIDEO Descriptions Description 3 Bi-directional RS-232 Control Application Example. Description 4 Bi-directional Ethernet Signal Application Example.
-
Page 10: Application Example
NEUVIDEO Application Example Application Example... -
Page 11: Ir Description
NEUVIDEO ir DESCRIPTION ir DESCRIPTION... - Page 12 BY, THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
