Dataman -448PRO2 User Manual page 27

Microcontrollers Nordic Semiconductor: nRF24xxx
Microcontrollers NEC: uPD7xxx series
Microcontrollers Philips (NXP): LPC1xxx, LPC2xxx, LPCxx series, 89xxx series
Microcontrollers Renesas: R8C/Tiny series
Microcontrollers Realtek, M-Square
Microcontrollers Scenix (Ubicom): SXxxx series
Microcontrollers STM: ST7xxx, STR7xx, STR9xx, STM32Fxx, STM8A/S/L series
Microcontrollers Silicon Laboratories(Cygnal): C8051 series
Microcontrollers & Programmable System Memory STMicroelectronics: uPSD, PSD series
Microcontrollers TI: MSP430 (both JTAG and BSL series), MSC12xxx series
Microcontrollers ZILOG: Z8Fxxxx, Z8FMCxxxxx, Z16Fxxxx series, ZLF645x0xx
Various PLD (also by Jam/VME/SVF/STAPL/... Player/JTAG support):
Altera: MAX 3000A, MAX 7000A, MAX 7000B, MAX 7000S, MAX 9000, MAX II/G/Z
Xilinx: XC9500, XC9500XL, XC9500XV, CoolRunner XPLA3, CoolRunner-II
PLD Lattice: ispGAL22xV10x, ispLSI1xxxEA, ispLSI2xxxE, ispLSI2xxxV, ispLSI2xxxVE,
ispLSI2xxxVL, M4-xx/xx, M4LV-xx/xx, M4A3-xx/xx, M4A5-xx/xx, LC4xxxB/C/V/ZC/ZE,
ispCLOCK, Power Manager/II, ProcessorPM
FPGA: Actel: ProASIC3, IGLOO, Fusion
FPGA: Lattice: MachXO, LatticeXP, ispXPGA
Note: For a full list of supported devices, please visit our website www.dataman.com.
Package support
support all devices in DIP with default socket
package support includes DIP, SDIP, PLCC, JLCC, SOIC, SOP, PSOP, SSOP, TSOP,
TSOPII, TSSOP, QFP, PQFP, TQFP, VQFP, QFN (MLF), SON, BGA, EBGA, FBGA,
VFBGA, UBGA, FTBGA, LAP, CSP, SCSP etc.
support devices in non-DIP packages up to 48 pins with universal adapters
programmer is compatible with third-party adapters for non-DIP support
Programming speed
DATAMAN-448PRO2
Device
K8P6415UQB (parallel NOR Flash)
MT29F1G08ABAEAWP (parallel NAND Flash) *2
THGBM3G4D1FBAIG (eMMC NAND Flash) *2
QB25F640S33 (serial Flash)
AT89C51RD2 (microcontroller)
PIC32MX360F512L (microcontroller)
Conditions:
*1 implementation is the same as in card readers. Verification of programming is performs
internal controller. Internal controller confirms the proper programming using status register.
*2 the programming time is for TurboMode active.ing status register.
SOFTWARE
Algorithms: only manufacturer approved or certified algorithms are used.
Size [bits]
400100hx16 bit (64 Mega)
8400000Hx8 (1 Giga)
2048 MB x8 (16 Giga)
800200Hx8 (64 Mega)
10000Hx8
80000Hx8
Intel Core2Duo 6300 1.86GHz, 1GB RAM, USB 2.0 HS, Win XP,
software PG4UW v3.03.
27
DATAMAN-448PRO2
Operation
programming and verify
programming and verify
programming *1
programming and verify
programming and verify
programming and verify
Time
13 sec
51 sec
363 sec
30.7 sec
14.4 sec
8.9 sec
