BT7513
SMALL FLAT SCREEN WALL MOUNT
WITH DOUBLE ARM EXTENSION
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
COMMUNITY DESIGN No. 001713280-0006
COMPATIBLE
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Optional Accessories........................................................................................................................10
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
INSTALLATION TOOLS REQUIRED
Crosshead
screwdriver
B-TECH AUDIO VIDEO MOUNTS
CONTENTS
8mm (5/16") masonry bit
Drill
or 4mm (5/32") wood bit
www.btechavmounts.com
FEATURES
●
Designed for flat screens up to 23" (58cm) / 15kg (33lbs)
●
Fits 75 x 75mm and 100 x 100mm VESA mounting patterns
●
Mounts screen from 95mm - 467mm from wall
●
Tilts +17°, -10°
●
Three swivel points: 180° at wall, 360° at central pivot and
240° at interface
●
Allows 360° rotation of screen in any direction to display
screen in landscape or portrait style
●
Features post installation screen levelling
●
Security locking screws and Allen key provided for a secure installation
●
Simple hook-on installation with all mounting hardware included
Pencil
Stud finder
(optional)
Advertisement
Related Manuals for B-Tech Mountlogic BT7513
Summary of Contents for B-Tech Mountlogic BT7513
-
Page 1: Table Of Contents
COMPATIBLE CONTENTS Installation Safety Notes........................2 Parts List.............................4 Installation Instructions........................6 Optional Accessories........................10 Product Dimensions..........................11 B-Tech Contact Details........................12 INSTALLATION TOOLS REQUIRED Pencil Stud finder 8mm (5/16") masonry bit Drill Crosshead (optional) or 4mm (5/32") wood bit screwdriver B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com... -
Page 2: Installation Safety Notes
Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire. - Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.
-
Page 4: Parts List
BT7513 PARTS LIST WALL PLATE, ARM & TILT PLATE ASSEMBLY Suitable for loads up to 15kg (33lbs) - Page 5 PART NAME WALL PLATE LEFT COVER PLATE RIGHT COVER PLATE EXTENSION ARM LOWER EXTENSION ARM M8 x 42mm PIN HEX SECURITY SCREW M8 PLASTIC WASHER M8 PIVOT SCREW M8 x 17.5mm SPACER U-PIECE M8 PLASTIC WASHER TILT PLATE M8 x 12mm PIN HEX SECURITY SCREW M8 NYLOC NUT INTERFACE PLATE M8 METAL WASHER...
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Fix wall plate to the wall using one of the following methods. i. Concrete / brick walls. 8mm (5/16") masonry bit ii. Wood / stud walls. ATTACH COVER PLATES STUD FINDER (Optional) 4mm (5/32") wood bit... - Page 7 Attach the interface to the flat screen. FLAT SCREEN Hook on the flat screen onto the tilt plate. WALL FLAT SCREEN...
- Page 8 Secure in position and adjust tilt. -10° +17° FLAT SCREEN To fix extension arm position, tighten parts 6 and 8.
- Page 9 Levelling the screen. 360° Optional - Storage for hex keys...
-
Page 10: Optional Accessories
FLAT SCREEN CAUTION: Ensure there is adequate cable slack for movement of the screen, and that cables will not be pinched when the mount is closed. OPTIONAL ACCESSORIES B-Tech AV Component Shelves & Cable Management. BT7087 BT7070 BT7077 BT7070 BT7078... -
Page 11: Product Dimensions
100mm 75mm 114mm 3.9" 3" 4.5" 0.2" 75mm 8.5mm 3" 0.3" 6.5mm 100mm 50mm 0.3" 3.9" 2" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT. -
Page 12: B-Tech Contact Details
©2010 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech, Better By Design, System 2 and Mountlogic are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
