BT7502
VESA ADAPTOR PLATE
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Adaptor Plate
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions............................................................................................................................7
B-Tech Contact Details.......................................................................................................................8
2.5mm Pin Hex
Security Key
(Supplied)
B-TECH AUDIO VIDEO MOUNTS
FEATURES
● Adaptor plate for flat screens which have holes in
200mm x 200mm or 200 x 100mm patterns
● Must be used with a VESA 75mm x 75mm or
100mm x 100mm screen mount
● Suitable for flat screens using M4, M5 and M6 fixings
● Theft-deterrent security features as standard
● All mounting hardware & fixings included
Actual screen size and weight limit dependent
CONTENTS
TOOLS REQUIRED
3mm Pin Hex
Security Key
(Supplied)
www.btechavmounts.com
on mount to which BT7502 is attached
4mm Pin Hex
Security Key
(Supplied)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for B-Tech BT7502
Summary of Contents for B-Tech BT7502
- Page 1 ● Suitable for flat screens using M4, M5 and M6 fixings ● Theft-deterrent security features as standard ● All mounting hardware & fixings included Actual screen size and weight limit dependent on mount to which BT7502 is attached CONTENTS Installation Safety Notes........................2 Parts List.............................4 Installation Instructions........................6...
- Page 2 Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire.
- Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.
- Page 4 BT7502 PARTS LIST WARNING: THIS SIDE TO SCREEN...
- Page 5 PART NAME ADAPTOR PLATE M4 x 8mm PIN HEX SECURITY SCREW 2.5mm PIN HEX SECURITY KEY (FOR PARTS 2 & A) 3mm PIN HEX SECURITY KEY (FOR PARTS B & C) 4mm PIN HEX SECURITY KEY (FOR PARTS D & E) INTERFACE KIT M4 x 12mm PIN HEX SECURITY SCREW M5 x 16mm PIN HEX SECURITY SCREW...
- Page 6 INSTALLATION INSTRUCTIONS i. Attach VESA mount (75 x 75mm or 100 x 100) to BT7502. VESA mount interface plate ii. Attach to flat screen. 3 4 5 FLAT SCREEN...
- Page 7 BT7502 PRODUCT DIMENSIONS 200mm 7.9" 100mm 3.9" 75mm 3" 214mm 8.4" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
- Page 8 ©2010 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech, Better By Design, System 2 and Mountlogic are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
