REG. DESIGN NO: 3014344
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Additional Mounting Options.............................................................................................................10
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
INSTALLATION TOOLS REQUIRED
Crosshead / Flathead
screwdriver
B-TECH AUDIO VIDEO MOUNTS
BT7510
FLAT SCREEN WALL MOUNT
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
CONTENTS
8mm (5/16") masonry bit
Drill
or 4mm (5/32") wood bit
www.btechavmounts.com
FEATURES
● Designed for screens up to 23" (53cm) / 20kg (44lbs)
● Fits screens with VESA mounting patterns:
50mm x 50mm, 75mm x 75mm and 100mm x 100mm
● Low profile design mounts screen only 15mm (0.6")
from wall
● Simple 'hook-on' installation with all mounting
hardware included
Pencil
Stud finder
Level
(optional)
(optional)
Advertisement
Related Manuals for B-Tech MountLogic BT7510
Summary of Contents for B-Tech MountLogic BT7510
-
Page 1: Table Of Contents
Parts List.............................4 Installation Instructions........................6 Additional Mounting Options......................10 Product Dimensions..........................11 B-Tech Contact Details........................12 INSTALLATION TOOLS REQUIRED 8mm (5/16") masonry bit Crosshead / Flathead Drill Pencil Stud finder Level or 4mm (5/32") wood bit screwdriver (optional) (optional) B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com... -
Page 2: Installation Safety Notes
Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. - Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.
-
Page 4: Parts List
BT7510 PARTS LIST IMPORTANT This mount must be disassembled prior to installation. Suitable for loads up to 20kg (44lbs) - Page 5 PART NAME FLAT SCREEN INTERFACE KIT WALL PLATE (FOR ATTACHING MOUNT TO BACK OF FLAT SCREEN) INTERFACE PLATE M4 X 8mm PIN HEX SECURITY SCREW 2.5mm PIN HEX SECURITY KEY (FOR PARTS 3 & A) INTERFACE KIT M4 X 12mm PIN HEX SECURITY SCREW FIXING KIT M5.5 X 40mm WOOD SCREW M6 METAL WASHER...
-
Page 6: Installation Instructions
THIS MOUNT MUST BE DISASSEMBLED PRIOR TO INSTALLATION INSTALLATION INSTRUCTIONS Fix wall plate to the wall using one of the following methods. i. Brick / concrete walls. 8mm (5/16") masonry bit... - Page 7 ii. Wood / wood stud walls. STUD FINDER (Optional) 4mm (5/32") wood bit...
- Page 8 Attach interface plate to back of the screen. FLAT SCREEN i. Hook screen onto wall plate. FLAT SCREEN WALL...
- Page 9 Secure the screen. FLAT WALL SCREEN OPTIONAL ACCESSORIES B-Tech AV Component Shelves & Cable Management. BT7087 BT7070 BT7077 BT7070 BT7078...
-
Page 10: Additional Mounting Options
ADDITIONAL MOUNTING OPTIONS BT7850 BT7052 This product is compatible with the System 2 range of professional install products from B-Tech Pole Installations ii. Vertical Pole i. Horizontal Pole SAMPLE INSTALLATIONS BT7510 BT7822 BT7260 BT7052 BT7052 BT7510 BT7510 BT7325 BT7325 BT7850... -
Page 11: Product Dimensions
0.4" 1.4" 114mm 4.5" 83mm 24mm 3.3" 0.9" 12° 39° 10mm 0.2" 0.4" 83mm 3.3" 88mm 3.5" These instructions are intended as a guide only and B-Tech accepts no liability for the accuracy of the information contained in this document. -
Page 12: B-Tech Contact Details
©2010 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech, Better By Design, System 2 & Mountlogic are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
