- Page 1 MANUAL ENGLISH Pure-10A 10” Full Range Top Cabin Order code: D3719 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Overview ..................................6 Back ....................................7 Installation ................................... 9 Setup and Operation ..............................10 Connection Example 1 (2 x Pure-10A/Pure-12A/Pure-15A and 2 x Pure-15AS/Pure-18AS) ......10 Connection Example 2 (2 x Pure-10A/Pure-12A/Pure-15A and 1 x Pure-15AS/Pure-18AS) ......11 Control Panel ................................12 Main Menu Options ..............................12 1. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● DAP Audio Pure-10A 10” Full Range Top Cabin ● Pro power cable (1,5 m) ●... - Page 4 Only use device indoors, avoid contact with water or other liquids. ● Prevent distortion! Make sure that all components connected to the Pure-10A have sufficient power ratings. Otherwise distortion will be generated because the components are operated at their limits.
-
Page 5: Operating Determinations
You endanger your own safety and the safety of others! Improper installation can cause serious injuries and damage of property ! The Pure-10A speaker can be placed on a flat stage floor or be hung from a ceiling by means of the Speaker hanging eye (D8436). -
Page 6: Return Procedure
Pure-10A 10” Full Range Top Cabin Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 7: Description Of The Device
Description of the device Features The DAP Audio Pure-10A is an active full range 10" speaker. It is a very compact, powerful and versatile cabinet, suitable for mobile applications as well as rental companies or fixed installations. The cabinet is constructed out of birch plywood with a scratch-resistant finish that can handle the rough life on the road. -
Page 8: Back
Move the switch to select one of the 3 ‘link’ modes: ● CH1: The Pure-10A will send the signal received on input 1 to the connected speaker. ● CH2: The Pure-10A will send the signal received on input 2 to the connected speaker. - Page 9 Pure-10A 10” Full Range Top Cabin Fig. 03 12) Pro power connector (Gray) THROUGH 13) Combo 3-pin XLR/6,3 mm jack connector, INPUT 2 Connect a line level device or a microphone. 14) Gain control, INPUT 2 Turn the control to set gain for input 2.
-
Page 10: Installation
Pure-10A 10” Full Range Top Cabin Installation Remove all packing materials from the Pure-10A. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. -
Page 11: Setup And Operation
Do not attempt to operate a 110 V specification product on 230 V power, or vice versa. Connection Example 1 (2 x Pure-10A/Pure-12A/Pure-15A and 2 x Pure-15AS/Pure-18AS) Make your initial connections with all the equipment powered off and ensure that all the main volume controls are turned completely to the minimum. -
Page 12: Connection Example 2 (2 X Pure-10A/Pure-12A/Pure-15A And 1 X Pure-15As/Pure-18As)
Pure-10A 10” Full Range Top Cabin Connection Example 2 (2 x Pure-10A/Pure-12A/Pure-15A and 1 x Pure-15AS/Pure-18AS) Make your initial connections with all the equipment powered off and ensure that all the main volume controls are turned completely to the minimum. Follow the steps below. -
Page 13: Control Panel
Pure-10A 10” Full Range Top Cabin Control Panel Press and turn the control to navigate through the menu options. Fig. 07 Display Off after 60 seconds When the control (19) is neither pressed or turned for 60 seconds, the display will turn off. -
Page 14: Preset
Pure-10A 10” Full Range Top Cabin 1. Preset In this menu you can set the desired preset. 01) Turn the control (19) to select one of the 5 presets: 02) Press the control (19) to confirm. 2. Low EQ In this menu you can set the low equalizer. -
Page 15: High Pass
Pure-10A 10” Full Range Top Cabin 5. High Pass In this menu you can set the high pass filter frequency. 01) Turn the control (19) to select one of the 6 options: 02) Press the control (19) to confirm. 6. Delay In this menu you can set the delay. -
Page 16: Front Led
Pure-10A 10” Full Range Top Cabin 9. Front LED In this menu you can set the function of the front LED located underneath the grill. 01) Turn the control (19) to select one of the 3 options: ● CLIP: If a received signal is too strong, the LED will light in red. -
Page 17: Lock
Pure-10A 10” Full Range Top Cabin 13. Lock In this menu you can set the menu lock. 01) Turn the control (19) to select one of the 2 options: ● OFF: The menu lock is inactive. ● ON: If the control is not pressed/turned for 60 seconds, the display will turn off. In order to access the main menu, turn and press the control (19) to insert the password. -
Page 18: Store
Pure-10A 10” Full Range Top Cabin 16. Store In this menu you can store the device’s current settings. 01) Turn the control (19) to select a desired slot. There are 6 slots. 02) Press the control (19) to confirm. 03) Turn the control (19) to select the character that needs to be edited. The NAME indicator will show its number (01–18). -
Page 19: Reset
Pure-10A 10” Full Range Top Cabin 18. Reset In this menu you can restore the factory default settings. 01) Turn the control (19) to select one of the 2 options: ● NO: Return to the main menu. ● YES: Restore the factory default settings. -
Page 20: Connection Cables
Pure-10A 10” Full Range Top Cabin Connection Cables Take care of your cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability. Periodically check your cables. -
Page 21: Maintenance
04) If all appears to be O.K., plug the unit in again. 05) If you are unable to determine the cause of the problem, do not open the Pure-10A, as this may damage the unit and the warranty will become void. -
Page 22: Product Specifications
Pure-10A 10” Full Range Top Cabin Product Specifications Model: Pure-10A 10” Full Range Top Cabin System: 2-way Active Bass-reflex Power supply: 120/230 V AC, 50/60 Hz Power RMS: 130 W RMS (low driver), 19,3 W RMS (high driver) Speaker low: 10", 4 Ω, 50 mm Voice coil... - Page 23 Pure-10A 10” Full Range Top Cabin Order code: D3719...
- Page 24 ©2020 DAP Audio...
