Example: MODE FIX
Query syntax: [SOURce:] MODE？
Return parameter: <CRD>
Usage:
MODE FIX command can also be used to stop a list execution.
[SOURce:]CURRent [:LEVel]
This command sets the current value of the power supply.
Command syntax: [SOURce:]CURRent [ : LEVel] <NRf>
Parameter: MIN TO MAX|MIN|MAX
Unit: A mA
*RST value: MIN
Example: CURR 3A， CURR 30mA， CURR MAX，
Query syntax: [SOURce:]CURRent [:LEVel]?
Parameter: [MIN|MAX]
Example: CURR? , CURR? MAX, CURR? MIN
Return parameter: <NR2>
[SOURce:]VOLTage[:LEVel]
This command sets the voltage value of the power supply.
Command syntax: [SOURce:]VOLTage[:LEVel] <NRf>
Parameter: MIN TO MAX|MIN|MAX
Unit: V mV kV
*RST value: MAX
Query syntax: [SOURce:]VOLTage[:LEVel]?
Parameter: [MIN|MAX]
Return parameter: <NR2>

List File Commands

List file operations can be executed using standard SCPI commands. The commands must be executed in a
certain order to successfully complete a list file.
Below is an example that demonstrates how to set a list in continuous mode with correct command order.
LIST:MODE CONT
LIST:STEP ONCE
LIST:COUNT 2
LIST:VOLT 1,2
LIST:VOLT 2,4
LIST:UNIT SECOND
LIST:WID 1,1
LIST:WID 2,2
LIST:NAME 'TEST'
LIST:SAVE 1
MODE LIST
Note: Be sure to specify LIST:AREA prior to using a set of list commands similar to above.
For details on setting values for each commands, refer to the descriptions below.
[SOURce:]LIST:MODE
This command sets the trigger condition for executing the list file
CONTinious List ope ration is continuous m ode.
CURR MIN
