Package contents
Check your motherboard package for the following items.
Motherboard
Cables
Accessories
Application DVD
Documentation
If any of the above items is damaged or missing, contact your retailer.
PRIME H110M2/FPT specifications summary
CPU
Chipset
Memory
Graphics
Expansion
slots
Storage
vi
ASUS PRIME H110M2/FPT motherboard
2 x Serial ATA 6.0 Gb/s cables
1 x I/O Shield
1 x Support DVD
1 x User Manual
LGA1151 socket for 7th/6th Generation Intel
processors
Supports 14nm CPU
Supports Intel
Turbo Boost Technology 2.0*
®
* The Intel
Turbo Boost Technology 2.0 support depends on the CPU types.
®
** Refer to www.asus.com for Intel
Intel
H110 Chipset
®
4 x DIMMs, max. 64 GB, DDR4 2400 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
* If you want to use one/two single-sided/double-sided memory module(s), install them into
the grey DIMM sockets (DIMM_A2, DIMM_B2).
** Due to Intel
chipset limitation, this motherboard can only support single-sided memory
®
modules when four modules are installed and they will run at the maximum transfer rate of
DDR4 1866 MHz.
*** Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please
refer to Memory QVL (Qualified Vendors List) for details.
**** Refer to www.asus.com for the Memory QVL(Qualified Vendors List).
Integrated Intel
graphics processor
®
Multi-VGA output support: DisplayPort/HDMI/DVI-D/D-Sub ports
- Supports DisplayPort with max. resolution of 4096 x 2160 @60Hz
- Supports HDMI with max. resolution of 4096 x 2160 @24Hz/ 2560 x 1600 @60Hz
- Supports DVI-D with max. resolution of 1920 x 1200 @60Hz
- Support D-sub port with max. resolution of 1920 x 1200 @60Hz
Supports up to two displays simultaneously
Maximum shared memory of 1024 MB
1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
1 x PCI Express 2.0 x16 slot (max. at x4 mode)
2 x PCI slots
Intel
H110 Chipset
®
- 4 x Serial ATA 6.0 Gb/s connectors (gray)
(continued on the next page)
Core™ i7/ i5/ i3, Pentium
®
CPU support list.
®
and Celeron
®
®
