Front panel audio connector (10-1 pin AAFP)
This connector is for a chassis‑mounted front panel audio I/O module that supports
either HD Audio or legacy AC`97 audio standard. Connect one end of the front
panel audio I/O module cable to this connector.
•
•
PCI Express 3.0/2.0 x16 slots
This motherboard supports two PCI Express x16 graphic cards that comply with the
PCI Express specifications.
PCI slots
The PCI slot supports cards such as a LAN card, SCSI card, USB card, and other
cards that comply with PCI specifications.
1‑4
We recommend that you connect a high‑definition front panel audio module to this
connector to avail of the motherboard's high‑definition audio capability.
If you want to connect a high‑definition front panel audio module to this connector,
set the Front Panel Type item in the BIOS setup to [HD Audio]. If you want to
connect an AC'97 front panel audio module to this connector, set the item to
[AC97]. By default, this connector is set to [HD Audio].
Chapter 1: Product introduction
