Product introduction
Motherboard overview
•
Unplug the power cord from the wall socket before touching any component.
•
Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
•
Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
•
Unplug the power cord before installing or removing the motherboard. Failure to do so
can cause you physical injury and damage to motherboard components.
KBMS_USB56
Place this
side towards
DP
the rear of the
chassis
LAN_USB3_34
AUDIO
17
16
15
AAFP
Scan the QR code to get the detailed pin definitions.
ASUS PRIME H110M2/FPT
1
ATX12V
CHA_FAN
RTL
BATTERY
8111F
PRIME H110M2/FPT
Super
PCI1
I/O
PCI2
ALC
887- VD2
SPDIF_OUT
COM2
LPT
14
13
12
11
2
3
22.6cm(8.9in)
CPU_FAN
DIGI
+VRM
LGA1151
PCIEX16_1
ASM
1083
PCIEX16_2
USBE12
USBE34
USB78
10
1
4
USB3_12
Intel
®
H110
SATA6G_3
128Mb
BIOS
SATA6G_4
F_PANEL
SPEAKER
6
9
8
7
1
5
6
1-1
