ATX power connectors (24-pin EATXPWR, 8-pin ATX12V)
These connectors are for ATX power supply plugs. The power supply plugs are
designed to fit these connectors in only one orientation. Find the proper orientation
and push down firmly until the connectors completely fit.
•
•
•
•
CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN)
Connect the fan cables to the fan connectors on the motherboard, ensuring that the
black wire of each cable matches the ground pin of the connector.
Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside
the system may damage the motherboard components. These are not jumpers! Do not
place jumper caps on the fan connectors! The CPU_FAN connector supports a CPU fan
of maximum 1A (12 W) fan power.
Intel
LGA1151 CPU socket
®
Install Intel
for 7th/6th Generation Intel
For more details, refer to Central Processing Unit (CPU).
DDR4 DIMM slots
Install 2 GB, 4 GB, 8 GB, and 16 GB unbuffered non‑ECC DDR4 DIMMs into these
DIMM sockets.
For more details, refer to System memory.
USB 3.0 connector (20-1 pin USB3_12)
Connect a USB 3.0 module to this connector for additional USB 3.0 front or rear
panel ports. This connector complies with USB 3.0 specifications and provide
faster data transfer speeds of up to 5 Gbps, faster charging time for USB‑
chargeable devices, optimized power efficiency, and backward compatibility with
USB 2.0.
1-2
We recommend that you use an EATX 12V Specification 2.0‑compliant power
supply unit (PSU) with a minimum of 300W power rating. This PSU type has 24‑pin
and 8‑pin power plugs.
DO NOT forget to connect the 4‑pin/8‑pin ATX +12V power plug. Otherwise, the
system will not boot up.
We recommend that you use a PSU with higher power output when configuring a
system with more power‑consuming devices or when you intend to install additional
devices. The system may become unstable or may not boot up if the power is
inadequate.
If you are uncertain about the minimum power supply requirement for your system,
refer to the Recommended Power Supply Wattage Calculator at http://support.
asus.com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en‑us for
details.
LGA1151 CPU into this surface mount LGA1151 socket, which is designed
®
Core™ i7 / i5 / i3, Pentium
®
, and Celeron
processors.
®
®
Chapter 1: Product introduction
