Table 5. DC590 Jumper Selection. Refer to the DC590 Demo Manual for Further Details.
JUMPER
JP1
JP2
JP3
JP4
JP5
JP6
8
SETTING OPERATION
PROG Microcontroller in-circuit programming header. Do NOT install jumper; make no
connections.
MODE Do NOT install jumper; make no connections.
Watchdog Enables Do NOT install jumper; make no connections.
EE Jumper MUST be in the EN position.
SW MUST be in the ON position.
(Right Hand Side) See Connections section.
ISO Controls the isolated supply.
(Left Hand Side) See Connections section.
VCCA Control See Connections section.
