Startup
After the IP phone is connected to the network and
supplied with power, it automatically begins the
initialization process. Once the IP Phone is initialized, it
displays two different phone modes - Standard SIP and
Extended SIP. Select the desired mode. You can configure
the phone via web user interface or phone user interface.
Configuring the IP Phone in Extended Mode
Configuring via web user interface
Accessing the web user interface:
1. Swipe down from the top of the screen to enter the control center.
2. Tap Setting->Status to obtain the IP address of the phone.
3. Open a web browser on your computer, enter the IP address into the address bar
(e.g., "http://192.168.0.10" or "192.168.0.10"), and then press Enter.
4. Enter the user name (default: admin) and password (default: admin) in the login page and click
Confirm.
Network Settings: Click on Network->Basic->IPv4 Config
You can configure the network settings in the following ways:
DHCP: By default, the phone attempts to contact a DHCP server in your network to obtain
its valid network settings, e.g., IP address, subnet mask, gateway address and DNS address.
Static IP Address: If the phone cannot contact a DHCP server for any reason, you need to
configure IP address, subnet mask, gateway address, primary DNS address and secondary
DNS address for the phone manually.
PPPoE: If you are using an xDSL modem, you can connect your phone to the Internet via
PPPoE mode. Contact the ITSP for the PPPoE user name and password.
Note: The IP phone has a provision for IPv6, but its support will be provided in future.
The Server Settings can be configured via phone user interface only.
The wrong network settings may result in inaccessibility of your phone and may have an impact on the
network performance. Contact your system administrator for more information.
Register status icons on the touch screen:
Registered
Note: Check with your system administrator if any error appears during the registration process or a specific
configuration is required for your registration.
Configuring via phone user interface
Sever Settings: Sever Settings:
1.After initialization, The MATRIX SOFWARE END USER LICENSE AGREEMENT (EULA) appears.
Tap I AGREE.
2.Tap the Matrix logo on the Start-up screen. Note the Device ID. Provide the same to your system
administrator. This needs to be configured in the Server. Refer to the respective Server System
Manual for details.
5
Registration Failed
Welcome
nitializing... Please wait
