I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Automated Wall Mount
CM7

Advertisement

Table of Contents
loading

Summary of Contents for CHIEF CM-7

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Installationsanleitung Instruções de Instalação Istruzioni di installazione Installatie-instructies Instructions d´installation Automated Wall Mount...
  • Page 2 DISCLAIMER Milestone AV Technologies, Inc., and its affiliated corporations and subsidiaries (collectively, "Milestone"), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product.
  • Page 3: Table Of Contents

    Important Safety Instructions Grounding Instructions CM7 Overview CM7 Specifi cations Certifi cations & Marks Installing CM7 Wood Stud Wall Installation Concrete Wall Installation Both Wood Stud & Concrete Wall Installation Using CM7 Setting CM7 TV width Adjusting the TV position Universal Remote Control Controlling CM7 with Home Automation (RJ11/RS232 port) Troubleshooting...
  • Page 4: Important Safety Instructions

    Important Safety Instructions WARNING: When using CM7, basic precautions should always be followed, including: • Read the entire users manual before attempting to use CM7. • Keep everything and everyone away from CM7 while in motion. Do not contact moving parts. •...
  • Page 5: Cm7 Overview

    CM7 Overview CM7 mount is a motorized mount for most fl at-panel TVs from 40” to 63” (101,6 to 160 cm), weighing up to 180 pounds (81 kg). CM7 allows a viewer to adjust the viewing angle of the TV with the touch of a remote control button.
  • Page 6: Cm7 Specifi Cations

    CM7 packaging includes: Zip Tie Screen Size Fasteners (X10) Selection Pointer Cross Plates (Optional) TV Mounting IR Receiver Hardware Velcro Tab CM7 Specifi cations Caution: CM7 mount is intended for use only with the maximum weight and TV widths indicated. Use with products heavier than the maximum weight or larger than the TV widths indicated may result in instability and cause injury.
  • Page 7: Installing Cm7

    Installing CM7 For concrete wall installation, go to the “Concrete Wall Installation” section. For wood stud wall installation continue below. Tools Needed Level Adhesive tape Wood Stud Wall Installation Locate wall studs 1-1.Using a stud fi nder, locate two wooden studs no more than 17”...
  • Page 8: Concrete Wall Installation

    Concrete Wall Installation Mark anchor locations 1-1. Remove the wall plate from the back of the CM7. First loosen the 2 security screws at the bottom, then lift the wall plate off the CM7. 1-2. Hold the wall plate up to the wall where you want the CM7 located.
  • Page 9 Set the CM7 TV width It is important to set the correct TV width on CM7 to avoid injury or property damage. The CM7 restricts movement based upon the TV width that is set. 5-1. Attach the power cord and connect the CM7 to a grounded power outlet. The CM7 power cord has a grounding conductor grounding plug.
  • Page 10 Route the Cables and IR Receiver CM7 is designed to hide cables and the TV power cord by passing them through the bellows to the wall. Use the cable-separating features built into CM7 to keep the power and AV cables separated to minimize electrical interference and binding as CM7 moves.
  • Page 11 If the power outlet for TV and CM7 is located inside the bellows of CM7, follow these directions. 7-1. Run A/V cables on the left side going over the bottom cross bar, through a cable loop and down AV Cable Loop Cable Tie Anchor Cable Bar Cable Hole...
  • Page 12 Attach adapters to CM7 (If Needed) Several optional attachments can be added to make the CM7 fi t TVs with non-standard hole spacing. Measure the width and height of the holes on the back of the TV to see if any adapters are needed. height Optional Bar Extensions - width of the TV holes is more than 26”...
  • Page 13 Optional Cross Plates - width of the TV holes is less than 21.50” (54.61 cm) Installation 1. Using a washer, lock washer and bolt, attach the two cross plates to the back of the TV. Make sure that the center is fl...
  • Page 14 Attach mounting brackets to the TV 9-1. Place the TV Mounting Brackets on the TV lined up with the mounting holes so that the hook is on the top. 9-2. Using a washer, lock washer and then a bolt, attach the brackets securely to your TV.
  • Page 15 Attach IR Receiver to TV 12-1. Using the provided velcro tab, adhere the IR receiver eye-piece to the TV so it has a clear line of sight with the remote control. Calibrate CM7 to Your TV IMPORTANT: CM7 must be calibrated to the TV to avoid hitting the wall. 13-1.
  • Page 16: Using Cm7

    Using CM7 Setting CM7 TV width NOTE: Do not repeat setting the width if you fi nished step 5 in the installation portion of this manual. Caution: CM7 restricts movement based upon the TV width selected by the user. The TV width must be set correctly before operating CM7.
  • Page 17: Universal Remote Control

    Universal Remote Control Once programmed, the universal remote can control TVs, VCRs, DVD Players and Cable boxes. See the pages following for instructions on how to program the remote. Power turns on/off the selected device. TV, once programmed to your TV, makes the TV the selected device.
  • Page 18 Programming the Universal Remote Once programmed, the universal remote can control TVs, VCRs, DVD Players and Cable boxes in addition to CM7. You can also set the preset buttons so that you can reposition CM7 to your favorite positions with one push of a button. Programming CM7 Preset Position Buttons Before using CM7, it is important that the correct TV width is set to avoid property damage or personal injury.
  • Page 19 TV Brand Code Numbers Admiral 220 160 081 072 Advent Aiwa Akai 146 001 Amark Ampro Amstrad Anam 242 131 080 056 043 058 004 001 Apex Audiovox Blaupunkt Broksonic Cairn Candel 004 003 002 001 Capehart Cetronic Citizen 143 103 101 043 004 003 002 001 Classic Concerto Contec...
  • Page 20 TV Brand Mitsubishi 225 146 124 109 042 040 031 028 021 024 004 Motorola 101 062 004 001 025 015 056 040 024 019 016 001 Nikei Olevia Onking Omwa Optonica 081 019 Orion Panasonic 250 249 238 227 164 080 056 034 017 033 Philco 164 064 063 060 059 056 024 004...
  • Page 21 DVD Player Programming To program the universal remote to operate your DVD Player: 1. Turn the DVD Player on. 2. Press the DVD and SET buttons together until the DVD button stays lit. 3. While pointing at the DVD Player, enter a 3-digit code from the code list for your DVD Player brand.
  • Page 22 VCR Programming Note that the VCR button is actually labelled DVD on the button, but VCR next to the button. To program the universal remote to operate your VCR: 1. Turn the VCR on. 2. Press the VCR (DVD) and SET buttons together until the DVD button stays lit. 3.
  • Page 23 Cable TV Set-Top Box Programming To program the universal remote to operate your Cable Box: 1. Turn the Cable Box and TV on. 2. Press the CBL and SET buttons together until the CBL button stays lit. 3. While pointing at the Cable Box, enter a 3-digit code from the code list for your Cable Box brand. Keep entering codes until the Cable Box powers off.
  • Page 24: Controlling Cm7 With Home Automation (Rj11/Rs232 Port)

    Controlling CM7 with Home Automation (RJ11/RS232 port) CM7 can be controlled through Home Automation remote controls and control panels such as those made by Crestron, AMX, Control4 and life|ware. To do this, do the following: 1. Using a philips screw driver, remove both screws from the cover plate located at the bottom, right-hand side of the control box.
  • Page 25: Troubleshooting

    Troubleshooting CM7 Will Not Move If CM7 becomes unresponsive, fi rst check to see what the LED display on the side of the CM7 control reads. Then choose a course of action based upon the code. “A1”, “A2”, or “A3” is displayed on control box Possible Causes: •...
  • Page 26 “C1”, “C2”, “C3” or “C4” is displayed on control box Normally CM7 will show the code associated with the TV mounted on it. 1. Check that the IR receiver is plugged into the side of the CM7 and that the IR Receiver eye is in direct line of sight with the remote control.
  • Page 27 “HC” is displayed on control box Possible Causes: • Person or object is obstructing the motion of the CM7. • One of the large drive screws has dirt or something on it. • The linkages are rubbing against something. • A motor cable has a short.
  • Page 28 “H1”, “H2”, or “H3” is displayed on control box Possible Causes: • A cable has become disconnected. • A “stop” switch is faulty. • There is dirty or debris in one of the switches. How to Correct: 1. Unplug CM7 from power. 2.
  • Page 29: Tv Does Not Fi T Cm7

    TV does not fi t CM7 1. Make sure that the TV is not too large or heavy for CM7: Maximum TV outside width accomodated: 40” - 63” (102 - 160 cm) Maximum weight limit: 180 lbs. (81 kg) 2. If mounting holes on TV back are too wide or narrow, an optional adapter may be needed.
  • Page 30 8820-000029RevC 2008 Chief Manufacturing www.chiefmfg.com 01/08 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615...
