Summary of Contents for CHIEF CMA165
- Page 1 PDF provided by Conference Room AV Chief CMA165 Internal Joist Ceiling Kit - Expands to Fit 16" or 24" Joists...
-
Page 2: Installation Instructions
I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Junction Box Ceiling Plate Assembly Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description CMA165... -
Page 3: Important Warnings And Cautions
It is the installer’s responsibility to make sure the combined weight of all components located attached to the CMA165 does not IMPORTANT WARNINGS AND exceed 50 lbs (22.7 kg). Use with products heavier than the... - Page 4 Installation Instructions CMA165 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
CMA165 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/32" 1/8" 5/32" - security (included) (included) (included) 7/16" 4" hole saw PARTS B (1) [Junction Box Assembly] A (1) [Ceiling Plate] F (1) E (1) [Security spinner] C (1) D (1) 5/32"... -
Page 6: Assembly And Installation
Place junction box onto U bar and tighten nuts. (See Figure 3) Determine the location for the CMA165. Cut hole in ceiling using a 4" hole saw. Lift the junction box assembly (B) bar into place above the ceiling. (See Figure 1) - Page 7 CMA165 Installation Instructions Install 1-1/2" NPT pipe (not provided) into ceiling plate. Secure pipe using one 10-24 x 1/4" set screw (L). (See Figure 4) OPTIONAL: Use one 10-24 x 1/4" button head security screw (H) and one security spinner (F) instead of the set screw (L) to add additional security to the ceiling plate installation.
- Page 8 Installation Instructions CMA165...
- Page 9 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
