CHIEF CM7W12U Specifications

automated mounts
cm7W12u
2 3
5
1
WHAT YOU nEED TO KnOW
multIple contRol optIons
IR Remote or Rs232
VoltaGe optIons
120V or 230V
flexIble on-Wall InstallatIon
InsTALLATIOn APPLICATIOn RECOMMEnDED ACCEssORIEs
CliCk
86
www.chiefmfg.com
37 - 63" Swing ArM
4
CAll
800.582.6480
FEATUREs
ultiMAtE FlEXibility
1
extends up to 12" (305 mm), tilts +7˚/-20˚ and
swivels up to 28˚ for maximum range of motion.
PrEsEt Positions
2
two preset buttons on remote to program
favorite viewing positions.
MultiPlE Control oPtions
3
control options include: rS232 interface, two
programmable viewing options, and ir remote
(included).
CAblE MAnAgEMEnt
4
Hidden cable management and mechanism
protected by decorative cover for finished look.
low ProFilE
5
collapses to 4.6" (305 mm), concealing mount
behind the screen.
sPECIFICATIOns
Extension
Tilt
swivel
Weight Capacity
Color
TECHnICAL DRAWInGs
31.06"
(789 mm)
6.34"
(161 mm)
4.25"
(108 mm)
26.57"
(675 mm)
4.6-12" (117-305 mm)
+7º, -20º
Up to 28º left/right
180 lbs (81.6 kg)
Black
22.64"
(575 mm)
5.98"
(152 mm)
FAX
877.894.6918
