Dynamic Mounting DOWN AND OUT Installation And Assembly Manual page 4

BEFORE YOU START
• Think about correct and comfortable placement.
• Verify the box contents are complete and not damaged.
• Gather appropriate tools and any necessary help.
• Verify the position and size of the mounting points on
the screen to be mounted.
sizes are supplied.)
• Consult any product specific mounting information
supplied by the TV manufacturer.
• Determine the approximate weight of the screen.
(Down and Out Mount is designed for TVs of between 20 to
120 lbs. Knowing the weight will allow you to pre-adjust the
counter weight mechanism to an approximate value before
)
mounting.
• Verify the substructure of the wall to be used.
necessary to locate the exact position of the studs, in a normal
wood-frame constructed wall.)
These instructions, and the materials supplied, are intended for the installation of the Down
WARNING!
and Out Mount with standard wood-stud framed walls. The Down and Out Mount may be
attached to walls with other forms of construction, however additional hardware and profes-
sional help may be required.
In all cases, the wall to be used must be rated to support a total weight equivalent to four times
the combined weight of both the TV and the Mount.
PLACEMENT
There are several factors to be considered for a proper and
safe placement of the Mount.
• Finding a comfortable viewing angle.
• Placing the TV and Mount, over a shelf or cabinet may
require careful calculation for an optimal result. (See
appendices)
• Placing the TV and Mount over a heat-source or fire-
place, may risk damage to equipment or cables.
• We recommended that in the UP position the TV is
high enough to be out of reach of children.
• Verify the availability of the necessary power and signal.
• The Mount and TV must be somewhat centered on the
framing in the wall to be used. (In the case of a heavy TV
this is especially important.) See NOTE **
NOTE ** If suitable framing is not available,
Mounting
offers the Extra-Wall-Support bracket. For
more information go to:
com/product/extra-wall-support
(Screws of different lengths and
Dynamic
https://www.dynamicmounting.
Down and Out Mount, installation and assembly.
www.DynamicMounting.com
(It will be
Using a stud finder to locate the studs in a stand-
ard wood frame constructed wall.
The Extra-Wall-Support bracket is avail-
able at
com/product/extra-wall-support
https://www.dynamicmounting.
4
