IFB Transmitter
IFBT4, IFBT4/E01, IFBT4/X
Fill in for your records:
Serial Number:
Purchase Date:
U.S. Patent 7,225,135
This guide is intended to assist with
initial setup and operation of your
Lectrosonics product.
For a detailed user manual, down-
load the most current
version at:
www.lectrosonics.com
20 May 2021
Advertisement
Table of Contents
Related Manuals for Lectrosonics IFBT4/E01
Summary of Contents for Lectrosonics IFBT4/E01
- Page 1 IFB Transmitter IFBT4, IFBT4/E01, IFBT4/X U.S. Patent 7,225,135 Fill in for your records: This guide is intended to assist with initial setup and operation of your Serial Number: Lectrosonics product. For a detailed user manual, down- load the most current...
- Page 2 Pressing the MENU button once from the Main window navigates to the Fre- quency window. The Frequency window displays the current operating frequency in MHz, as well as the standard Lectrosonics hex code for use with transmitters equipped with hex...
- Page 3 HVAC rumble, traffic noise or other low frequency sounds may degrade the quality of the audio. The 35 Hz setting may be used in the absence of adverse conditions, for a fuller bass response. Press MENU to return to the Setup window. www.lectrosonics.com...
- Page 4 Lectrosonics IFBR1A or a compatible IFB receiver. 400 - Lectrosonics 400 Series. This mode offers the best audio quality and is recommended if your receiver supports it. IFB - Lectrosonics IFB compatibility mode. This is the default setting and is the appropriate setting to use with the Lectrosonics IFBR1A or a com- patible IFB receiver.
- Page 5 MENU button for about 4 seconds. Continue holding the button as a progress bar extends across the LCD. When the bar reaches the right side of the screen, the unit will toggle to the opposite mode and LOCKED or UNLOCKED will flash briefly on the screen. www.lectrosonics.com...
- Page 6 MENU button while pressing and holding the Up button. The group tun- ing mode indicator will stop blinking to show that the frequency has been added to the group, or begin blinking to indicate that the frequency has been removed from the group. LECTROSONICS, INC.
- Page 7 6 VDC and as high as 18 VDC. External power sources must be able to supply 200 mA continuously. Antenna The ANTENNA connector is a standard 50 ohm BNC connector for use with standard coaxial cabling and remote antennas. www.lectrosonics.com...
