Summary of Contents for HUANUO HNCM3
- Page 1 Installation Instruction V2.0 support@huanuoav.com HNCM3...
-
Page 2: Unpacking Instructions
UNPACKING INSTRUCTIONS Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage. Check package contents against the Supplied Parts List in the next page to assure that all components were received undamaged. Do not use damaged or defective parts. Carefully read all instructions before attempting installation. -
Page 3: Phillips Screwdriver
Supplied Parts List Pole “C” Clamp “C” Clamp Brace Swivel Arm a (x1) b (x1) c (x1) d (x1) VESA Plate VESA Plate M4x6 Bolt e1 (x2) e2 (x1) f1 (x2) f2 (x1) M5x14 Bolt M8x12 Bolt M10 Bolt Support Plate g (x3) h (x2) i (x1) - Page 4 Step 1 Install the Pole to the Desktop Option A：Desk Clamp Assembly 1. Use 3 pieces M5x14 bolts(g) to install the C Clamp brace(c) to the Pole. Use the Allen Key(o) to tighten the bolts. See Figure 1. 2. According to the thickness of the desktop, Use 2 pieces M8x12 bolts(h) to install the C clamp(b) to C Figure 1 clamp brace (c).
- Page 5 Step 1 Install the Pole to the Desktop Option B: Grommet Base Assembly Existing Grommet Hole Installation 1. Position the Pole(a) on the mounting surface and mark the center hole. Drill a 3/8" (10mm) diameter hole at the marked position through the mounting surface.
- Page 6 Step 3A Attach the Side VESA Plates to the Monitors For Monitor with Curved For Monitor with Flat Back or Recessed Back Step 3B Attach the Center VESA Plate to the Monitor For Monitor with Curved For Monitor with Flat Back or Recessed Back...
- Page 7 Step 4A Slide the Side Monitors onto the Head of Swivel Arm Slide the monitor onto the head of Swivel Arm Install the security Nut(f1). Make sure the (d) as shown in the above diagram. security nut is installed before you rotate the monitor.
- Page 8 Step 5 Fix the Tilt Angle of Side and Center Monitors grub screw Fix the tilt angle Fix the tilt angle Tighten the bolt with the supplied Allen Key(o) to Fasten the grub screw in monitor arm to fix the fix the tilt angle.
- Page 9 Step 7 Fix the Tilt Angle of Side and Center Monitors Manage the wires and store the Allen keys(o) in Wire Clip(n1) for future use. Step 8 All Done...
- Page 10 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us. Telephone：800-556-0533 Mon-Fri 10am - 6pm (PST) (USA) Email：support@huanuoav.com...
