HUANUO HNCM9 Instruction Manual

Monitor stand

Hide thumbs Also See for HNCM9:

Monitor Stand Instruction Manual

English

Deutsch

Français

Español

Italiano

Thank you for choosing this HUANUO product! At HUANUO we strive to

provide you with the best quality products and services in the industry.

Should you have any issues, please don't hesitate to contact us at

Technical Support:

44-808-196-3874 Mon-Fri 2pm - 10pm (UTC)

Other Info:

support_eu@huanuoav.com (DE/UK/FR/IT/ES/NL/SE/AU/PL)

Model: HNCM9

------------------------------- 01-05

------------------------------- 06-10

------------------------------- 11-15

------------------------------- 16-20

------------------------------- 21-25

V3.0

Table of Contents

Need help?

Do you have a question about the HNCM9 and is the answer not in the manual?

Page 1 ------------------------------- 16-20 Italiano ------------------------------- 21-25 Thank you for choosing this HUANUO product! At HUANUO we strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us at...
Page 2 DO not install on a structure that is prone to vibration, movement or chance of impact. Reinforce the structure as required before installation. Don't use the product on particle board. Supplied Par ts List “C” Clamp Pole Set “C” Clamp Brace Swivel Arm b (x1) a (x1)
Page 3 Pre-Assembly the Pole Set Remove the grub screws by provided Allen Key (o). Connect the poles by threads as below diagram. Install the grub screws and fasten them by provided Allen Key(o).
Page 4 Install the Pole to the Desktop Step 1 Option A: Desk Clamp Install 1. Install the “C”-Clamp Brace(c) to the Pole (a) using 3pcs M5x14 Bolts(f), and tighten using the Allen Key(o), see Figure 1. 2. C-clamp (b) was mounted on the Clamp assembly according to the thickness of the table top.
Page 5 Step 2 Install Arm to the Pole Install Swivel Arm(d) to the Pole(a). Fasten the bolt with supplied Allen Key(o). Attach the Wire Clip(n1,n2) to the Pole(a) and Swivel Arm(d). For Monitor with Flat Back For Monitor with Curved or Recessed Back...
