Summary of Contents for HUANUO HNCM4
- Page 1 Installation Instruction V2.0 support@huanuoav.com HNCM4...
- Page 2 UNPACKING INSTRUCTIONS Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage. Check package contents against the Supplied Parts List in the next page to assure that all components were received undamaged. Do not use damaged or defective parts. Carefully read all instructions before attempting installation.
- Page 3 Supplied Parts List Pole Weighted Base Swivel Arm a (x1) b (x1) c (x1) VESA Plate M5x14 Bolt d (x2) e (x3) h (x2) M10 Bolt Support Plate M10 Washer Spring Washer i (x1) j (x1) k (x1) l (x1) Grommet Base Plate Wire Clip Wire Clip...
- Page 4 Step 1 Install the Pole to the Desktop Option A: Weighted Base Assembly 1. Install the Pole(a) to the Weighted Base(b) using 3pcs M5x14 Bolts(e), and tighten using the Allen Key(o), see Figure 1. 2. Optionally, you can drill a 10mm diameter hole in your desk and secure u s i n g t h e S u p p o r t P l a t e ( j ) , M 1 0 Washer(k), Spring Washer(l) and M10...
- Page 5 Step 1 Install the Pole to the Desktop Option B: Grommet Base Assembly Existing Grommet Hole Installation 1. Position the Pole(a) on the mounting surface and mark the center hole. Drill a 3/8" (10mm) diameter hole at the marked position through the mounting surface.
- Page 6 Step 3 Attach the VESA Plate to the Monitor For Monitor with Flat Back For Monitor with Curved or Recessed Back Step 4 Slide the Monitor onto the Head of Swivel Arm Slide the monitor onto the head of Swivel Install the security Nut(h).
- Page 7 Step 5 Fix the Tilt Angle and Adjust the Level of Monitor Ignore this step if Fix the tilt angle monitors are level Tighten the bolt with the supplied Allen Key(o) to If one monitor is lower, remove the Nut(h) and fix the tilt angle.
- Page 8 Step 7 All Done Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us.
