Monitor Stand
Instruction Manual
Model:HNCM5
Thank you for choosing this Huanuo product! At Huanuo we
strive to provide you with the best quality products and
services in the industry. Please share your experience of our
product with others at www.huanuoav.com/reviews if you
are satisfied. Should you have any issues, please don't
hesitate to contact us.
Technical Support:
1-800-556-0533 Mon-Fri 10am - 5pm (PST) (USA) (CAN)
Other Info:
support@huanuoav.com (US/CA/DE/UK/FR/IT/ES/AU)
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HUANUO HNCM5
Summary of Contents for HUANUO HNCM5
- Page 1 Monitor Stand Instruction Manual Model:HNCM5 Thank you for choosing this Huanuo product! At Huanuo we strive to provide you with the best quality products and services in the industry. Please share your experience of our product with others at www.huanuoav.com/reviews if you are satisfied.
- Page 2 IMPORTANT SAFTY INSTRUCTIONS Please carefully read all instructions before attempting installation. If you do not understand the instructions or have any concerns or questions, please contact our customer service at support@huanuoav.com CAUTION: Avoid potential personal injuries and property damage! Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 Allen Key Allen Key Bolt Bolt 5/32 in.(4mm) 15/64 in.(6mm) (A) X3 (B) X1 (C) X1 (D) X1 Bolt Bolt Bolt Bolt Washer Spacer M4x12mm M4x16mm M5x12mm M5x16mm M-A X4 M-B X4 M-C X4 M-D X4 M-E X4 M-F X4 Secure the Support Pillar [04] to the Base [03] Step 1 Option A...
- Page 4 Secure Cable Clip [05] and Monitor Connector [02] in Step 2 Sequence to the Support Pillar [04] Step 2-1 Slide the cable clip [05] and monitor connector [02] in sequence to the support pillar [04]. Step 2-2 Tighten monitor connector [02] to the support pillar [04] using Allen key [D]...
- Page 5 Select Monitor Bolts Step 3 Only one bolt size fits your monitor. Bolt length:Verify adequate thread engagement with bolts or bolts/spacers combination.We recommend thread engagement by at least 5 turns. -Too short will not hold the monitor. -Too long will damage the monitor. Attach the Monitor Plate to the Monitor Step 4 FLAT BACK MONITOR...
- Page 6 ROUND BACK MONITOR (UNIVERSAL MONITOR PLATE) M-B/M-D (If Needed) Hang Monitor to the Stand and Secure with Bolt [B]. Step 5...
- Page 7 Fix Tilt Angle of the Monitor Step 6 Manage Cables Step 7...
- Page 8 Store Allen Keys into the Cable Clip Step 8 D 15/64 in.(6mm) C 5/32 in.(4mm) Features 360° Tilt...
