- Page 1 Installation Instruction V2.0 HNCM2 support@huanuoav.com...
- Page 2 UNPACKING INSTRUCTIONS Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage. Check package contents against the Supplied Parts List in the next page to assure that all components were received undamaged. Do not use damaged or defective parts. Carefully read all instructions before attempting installation.
- Page 3 Supplied Parts List Pole “C” Clamp “C” Clamp Brace Swivel Arms a (x1) b (x1) c (x1) d (x2) VESA Plate M5x14 Bolt M8x12 Bolt e (x2) f (x3) g (x2) h (x2) M10 Bolt Support Plate M10 Washer Spring Washer i (x1) j (x1) k (x1)
- Page 4 Step 1 Install the Pole to the Desktop Option A：Desk Clamp Assembly 1.Use 3 pieces M5x14 bolts(f) to install the C Clamp brace(c) to the Pole. Use the Allen Key(o) to tighten the bolts. See Figure 1. 2.According to the thickness of the desktop, Use 2 pieces M8x12 bolts(g) to install the C clamp(b) to C Figure 1 clamp brace (c).
- Page 5 Step 1 Install the Pole to the Desktop Option B: Grommet Base Assembly Existing Grommet Hole Installation 1. Position the Pole(a) on the mounting surface and mark the center hole. Drill a 3/8" (10mm) diameter hole at the marked position through the mounting surface.
- Page 6 Step 3 Attach the VESA Plate to the Laptop Tray or Monitor For Monitor with Curved For Laptop For Monitor with Flat Back or Recessed Back Step 4 Slide the Monitor onto the Head of Swivel Arm Slide the monitor onto the head of Swivel Install the security Nut(h).
- Page 7 Step 5 Make the Necessary Adjustments Fix the tilt angle Tighten the bolt with the supplied Allen Key(o) to Use the supplied Allen Key(o) to make the fix the tilt angle. necessary adjustments. Step 6 Manage the Wires and Store the Allen Keys on Wire Clip...
- Page 8 Step 7 All Done Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us. Telephone：800-556-0533 Mon-Fri 10am - 6pm (PST) (USA) Email：support@huanuoav.com...
