9.4.1.1.
Tips for Getting the Best Camera Image
•
Too much brightness causes the image to fade. Too little brightness will cause dark colors to run together.
•
Too much contrast will cause obscured details. Too little contrast will cause the image to lose clarity and brightness.
•
Too much saturation will cause colors to be inaccurate. Too little saturation will cause the image to appear black and white.
•
Increase AGC only if contrast in the scene is too dark in some areas and too bright in others. Too much AGC can drastically
reduce image clarity in low-light scenes.
•
Lower shutter time values increase the amount of light available, but can increase movement blur. Higher shutter time values
decrease lighting, but motion is captured more clearly.
•
Leave Sense-Up OFF unless required for scenes containing very bright and dark areas at the same time (such as heavily
backlit windows).
•
DNR can reduce some digital noise that occurs in dimly lit scenes. Use the lowest setting that provides adequate image quality.
9.4.2. How to Configure Day and Night Settings (Color Modes)
The camera can record an image in color or black-and-white mode. Color mode requires more light but provides the best image
given ideal conditions. Black and white requires much less light, and the camera's IR can be turned on to illuminate the scene.
If the camera view is not ideal after installation, adjustments can be made to optimize the automatic settings or set them manually.
9.4.2.1.
Day & Night Modes
Select the mode from the Day and Night drop-down menu.
EXT Light
Sensor Mode
(Default)
Color Mode
(Day)
B&W Mode
(Night)
Time Mode
© 2014 Wirepath Surveillance
Uses camera light sensor to switch between Color (Day) and B&W (Night) modes.
See section
9.4.2.2. EXT Light Sensor Mode (Default Mode)
Forces camera to Color (Day) mode only. Useful for scenes that will be consistently lit and when color
video is always preferred. All sub-settings are disabled in Day mode. Use the Image Settings to adjust
the picture. See section
9.4.1. Image Settings Menu
Forces camera to B&W (Night) mode only, increasing low-light performance. Useful for scenes that
will consistently be poorly lit. Use the Image Settings to adjust the picture. See section
Settings Menu
for setup instructions
Forces camera to switch between Color and B&W modes at specific times. See section
Mode Setup
for setup instructions.
WPS-550-BUL-IP Installation Manual
for setup instructions.
for setup instructions.
9.4.1. Image
9.4.2.3. Time
43
