FLIR Extech EX510 User Manual page 15

Enclosure
Shock (Drop Test)
Diode Test
Continuity Check
Input Impedance
AC Response
ACV Bandwidth
Crest Factor
Display
Overrange indication
Auto Power Off
Polarity
Measurement Rate
Low Battery Indication
Battery
Fuses
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature
Operating Humidity
Storage Humidity
Operating Altitude
Weight
Size
Safety
Approvals
Copyright © 2012 Extech Instruments Corporation (a FLIR company)
All rights reserved including the right of reproduction in whole or in part in any form.
Double molded, waterproof (IP67)
2 meters (6.5 feet)
Test current of 0.9mA maximum, open circuit voltage 2.8V DC typical
Audible signal will sound if the resistance is less than 100Ω (approx.), test
current <0.35mA
>10MΩ VDC & >10MΩ VAC
Average responding
40Hz to 1kHz
≤3 at full scale up to 500V, decreasing linearly to ≤1.5 at 1000V
6,000 count backlit liquid crystal with bargraph
"OL" is displayed
15 minutes (approximately) with disable feature
Automatic (no indication for positive); Minus (-) sign for negative
2 times per second, nominal
" " is displayed if battery voltage drops below operating voltage
One 9 volt (NEDA 1604) battery
mA, µA ranges; 0.8A/1000V ceramic fast blow
A range; 10A/1000V ceramic fast blow
-20°C to 60°C (-4°F to 140°F)
Max 80% up to 31°C (87°F) decreasing linearly to 50% at 40°C (104°F)
<80%
2000meters (7000ft) maximum.
342g (0.753lb) (includes holster).
187 x 81 x 50mm (7.36" x 3.2" x 2.0") (includes holster)
This meter is intended for origin of installation use and protected, against
the users, by double insulation per EN61010-1 and IEC61010-1 2
(2001) to Category IV 600V and Category III 1000V; Pollution Degree 2.
The meter also meets UL 61010-1, 2
nd
61010-1 2 Edition (2004), and UL 61010B-2-031, 1
CE
www.extech.com
nd
Edition (2004), CAN/CSA C22.2 No.
15
nd
Edition
st
Edition (2003)
EX510-EU-EN-V3.3-1/12
