FLIR Extech EX510 User Manual page 14

Function
Resistance
Frequency
(electronic)
Frequency
(electrical)
Duty Cycle
Note: Accuracy specifications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit.
• (+ digits) – This is the accuracy of the analog to digital converter.
Range Resolution
600Ω 0.1Ω
6kΩ 0.001kΩ
60kΩ 0.01kΩ
600kΩ 0.1kΩ
6MΩ 0.001MΩ
40MΩ 0.01MΩ
9.999Hz 0.001Hz
99.99Hz 0.01Hz
999.9Hz 0.1Hz
9.999kHz 0.001kHz
99.99kHz 0.01kHz
999.9kHz 0.1kHz
9.999MHz 0.001MHz
40MHz 0.01MHz
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and <100kHz; 5Vrms min @ 20% to 80%
duty cycle and > 100kHz
10.00-400Hz 0.01Hz
Sensitivity: 15Vrms
0.1 to 99.9% 0.1%
Pulse width: 100µs - 100ms, Frequency: 5Hz to 150kHz
.
14
Accuracy
±(0.3% reading + 4 digits)
±(0.3% reading + 20 digits)
±(0.1% reading + 1 digits)
±(0.5% reading)
±(1.2% reading + 2 digits)
EX510-EU-EN-V3.3-1/12
