Specifications:

These characteristics apply to an adjusted GCP-300 AC/DC Current Probe
installed on an oscilloscope of any brand. The oscilloscope must be warmed
up for at least 20 minutes and be in an environment with the temperature at
10°C ~30°C and the humidity at 0~80%.
Table 2: Electrical Characteristics
Current Ranges
DC Accuracy, typical
Gain versus frequency, typical
Maximum Working Current
Maximum Working Voltage
Maximum Float Voltage
Frequency Range
Rise Time
Load Impedance:
Battery Type and Life, typical
DC signal linearity, typical
Phase shift, typical
NOTE: This clamp adapts to all measurement instruments which have a BNC input and an
impedance of 1MΩ, < 100 pF.
10/100 mV/A
±3% ±50 mA at 100 mV/A
(50 mA to 20 A peak range)
±4% ±50 mA at 10 mV/A
(500 mA to 80 A peak range)
±15% max at 10 mV/A
(80 A peak to 200 A peak range)
See Figure 6
See Table 3
See Table 3
See Table 3
DC to 300 KHz (-3 dB)
1.2 u
≥ 1MΩ, < 100pF
9V NEDA 1604A, IEC 6LR61
10 hours minimum (1 each)
See Figure 8
See Figure 9
12
(Typ.)
