Mounting
1. Disconnect the power supply.
2. The indicator mounted on a rail in the distribution box.
3. Using a screwdriver, remove the screws and remove the front
shield meter terminals.
4. Connect power to terminals 1 (L1 IN), 3 (L2 IN), 5 (L3 IN).
5. Connect the measured circuit or a single receiver to the ter-
minals in accordance with the markings to the terminals 2 (L1
OUT), 4 (L2 OUT), 6 (L3 OUT).
6. N-wire connect to terminal 7.
7. Additional pulse receiver connected to terminals 20(+) – 21(–).
The terminals are located under the top shell meter terminals.
Additional pulse receiver is not required.
8. Put the meter terminals covers.

Description of terminals

1, 3, 5
2, 4, 6
– L1, L2, L3 (power supply)
– L1, L2, L3 (receive)
7 – N-wire neutral
20 – pulse output (+)
21 – pulse output (–)
- 4 -
