- Page 1 User Manual OBM-H120 Extreme Super Bright Screen OBM-H120(12.1”) Professional Video Monitor Ver 20.1...
-
Page 2: Table Of Contents
Extreme Super Bright Screen OBM-H120 Professional Video Monitor Table of Contents 1. Precaution 2. Main Features 3. Location and Function of Parts and Controls Front Panel Rear Panel 4. Using the Menu 5. Adjustment Using the Menus 6. OSD Menu Operations... -
Page 3: Precaution
Extreme Super Bright Screen OBM-H120 Professional Video Monitor 1. Precaution Always use set voltage. DC 12V All these instruc ons should be read and understood before opera ng the unit. If liquid is spilled on or impacts this product, please disconnect the product immediately and seek profession- al help before con nued use. - Page 4 Extreme Super Bright Screen OBM-H120 Professional Video Monitor Do not a empt to service the product yourself. Removing covers can expose you to high voltage and other dangerous condi ons. Request a qualified service person to perform servicing. When the product needs replacement parts, make sure that the service person uses replacement parts specified by the manufacturer, or those with the same characteris cs and performance as the original parts.
-
Page 5: Main Features
Professional Video Monitor 2. Main Features The OBM-H120 offers the superior picture quality and wide viewing angle, and includes an array of professional features and the advanced audio & video signal analysis func ons including Waveform, Vector Scope, Audio Level Meter, IMD, Camera Log Selec on, Custom 3D LUT Import, Focus Assist, etc. The OBM H120 is equipped with various I/O interfaces such as 3G-SDI, HDMI, Component, Composite. -
Page 6: Location And Function Of Parts And Controls
Extreme Super Bright Screen OBM-H120 Professional Video Monitor 3. Location and Function of Parts and Controls Front Panel OBM-H120 A : Input select Bu ons/Lamp Press to monitor the signal input to each connector. [ANALOG] Bu on/Lamp [SDI-A] Bu on/Lamp - Press the bu on to select Analog Input. - Page 7 Extreme Super Bright Screen OBM-H120 Professional Video Monitor C : Func on Bu on/Lamp Press to adjust or turn/off each func on. [SCAN] Bu on - Press the bu on to adjust the scan mode. (Zero Scan, 1:1 Scan). [ASPECT] Bu on - Press the bu on to select the Aspect Ra o of the signal.
-
Page 8: Rear Panel
Extreme Super Bright Screen OBM-H120 Professional Video Monitor (headphone) Jack and USB connector Headphone Jack - The audio signal which is selected using the input select bu on is output in stereo sound. - When SDI signals are input, the audio signals of the channels selected with SDI Audio Se ng in the User Configura on menu are output. - Page 9 Extreme Super Bright Screen OBM-H120 Professional Video Monitor A : SDI IN (SDI Input) connectors (BNC) Input connectors for SDI signals. B : SDI OUT (SDI Output) connectors (BNC) Output connectors for SDI signals. Each connector outputs the signal which is input to the corresponding SDI IN connector.
- Page 10 Extreme Super Bright Screen OBM-H120 Professional Video Monitor G : SERIAL REMOTE IN/OUT connector (RJ-45) Used for the future func on expansion. Connects the monitor to control the program provided by the manufacturer by using RS-422/485 communica on or the external UMD(IMD) equipment and controls the monitor.
-
Page 11: Using The Menu
Extreme Super Bright Screen OBM-H120 Professional Video Monitor 4. Using the Menu This monitor is equipped with an OSD menu to make various adjustments and se ngs such as picture control, input se ng, set se ng change, etc. 2. Turn SEL/VOL knob to select a menu, 1. -
Page 12: Adjustment Using The Menus
Extreme Super Bright Screen OBM-H120 Professional Video Monitor 5. Adjustment Using the Menus The OSD menu of this monitor consists of the following items. Status menu (To indicate the current se ngs) Camera Assist menu Format Zebra & False Color... - Page 13 Extreme Super Bright Screen OBM-H120 Professional Video Monitor User Configura on menu Closed Cap on Se ng Closed Cap on Load User Preset Se ng Type Save Fast Mode Se ng Func on Bu on Se ng Fast Mode F1 Bu on...
-
Page 14: Osd Menu Operations
Extreme Super Bright Screen OBM-H120 Professional Video Monitor 6. OSD Menu Operations Status Menu The Status menu displays the current status of the Page 3/4 monitor. The following items are displayed. Page 1/4 SDI Input Iden fier SDI Payload ID... -
Page 15: Color Temp/Color Space/Gamma Menu
Extreme Super Bright Screen OBM-H120 Professional Video Monitor Color Temp/Color Space/Gamma Menu These menus are used for adjus ng or se ng the color Page 2/3 temperature, color space or gamma of the picture. Page 1/3 Color Space - Selects the color space between [ITU-R BT.709], [Na ve]. - Page 16 OBM-N090 : 200 cd/m² - The file name of the user log data is displayed OBM-H120 : 1000 cd/m² on the OSD up to 15 characters, and the log data file should be placed on the top folder of 2) PQ and HLG gamma is different, depending on...
-
Page 17: Camera Assist Menu
Extreme Super Bright Screen OBM-H120 Professional Video Monitor Camera Assist Menu Page 1/3 False Color Comparison - Allows the user to divide the picture side by side and compare the original image on the le half and the False Color image on the right half. -
Page 18: User Configuration Menu
Extreme Super Bright Screen OBM-H120 Professional Video Monitor User Configuration Menu Camera Assist Menu User Configura on consists of the adjustment Page 3/3 menus such as[User Preset],[Func on Bu on Se ng],[Input Se ng],[Speaker Out / Audio Level Meter Se ng],[Marker Se ng],[WFM/Vector Se ng], [Closed Cap on Se ng], [System Se ng]. - Page 19 Extreme Super Bright Screen OBM-H120 Professional Video Monitor User Configuration Menu Speaker Out / Audio Level Meter Se ng Page 2/7 - Selects the audio channel of the SDI & HDMI input signal. SDI : Le Speaker Out / Right Speaker Out...
- Page 20 Extreme Super Bright Screen OBM-H120 Professional Video Monitor User Configuration Menu Page 5/7 Page 4/7 WFM/Vector Se ng Marker Se ng WFM/Vector Marker - Select [On] to display the [WFM/Vector] and [Off] - Selects On to display the marker, and Off to not to display.
- Page 21 Extreme Super Bright Screen OBM-H120 Professional Video Monitor User Configuration Menu Page 7/7 Posi on - Sets the display posi on of the [WFM/Vector]. Selects [Right Bo om], [Le Bo om], [Le Top], or [Right Top]. Size Sets the size of Waveform and Vector Scope.
-
Page 22: Remote Menu
Extreme Super Bright Screen OBM-H120 Professional Video Monitor Page 2/3 Remote Menu Page 1/3 Monitor ID Sets the ID of the monitor to control the monitor through Serial Remote or Network. Parallel Remote Selects the Parallel Remote connector pins for In-Monitor Display Se ng which you want to change the func on. -
Page 23: Security Menu
Extreme Super Bright Screen OBM-H120 Professional Video Monitor Security Menu Remote Menu Page 3/3 Security Se ng Network Se ng Key Lock DHCP When Key Lock func on is set On, the change of - Toggle DHCP On or Off. -
Page 24: Available Signal Formats
Extreme Super Bright Screen OBM-H120 Professional Video Monitor 7. Available Signal Formats This monitor is applicable to the following signal formats HD-SDI Signal System Signal Format 1920x1080 / 4:2:2 YCbCr 10bit 23.98, 24, 25, 29.97, 30p/Psf, 50, 59.94, 60i 2048 x 1080 / 4:2:2 YCbCr 10bit 23.98, 24, 25, 29.97, 30p/Psf... -
Page 25: Key Functions
Extreme Super Bright Screen OBM-H120 Professional Video Monitor 8. Key Functions Focus Assist High Dynamic Range(HDR) Display Func on The OBM N series provides the func on to display the This func on controls the aperture level of a video High Dynamic Range footage. - Page 26 Extreme Super Bright Screen OBM-H120 Professional Video Monitor Black Stretch The Black Stretch increases the visibility of subjects in dark areas, not degrading image quality in bright areas. This mode can be used to increase shadow detail without changing the absolute black level, and without affec ng mid-tones.
- Page 27 Extreme Super Bright Screen OBM-H120 Professional Video Monitor Gamut Error Zebra pa ern or Color is displayed on the por on whose Y, Cb, Cr and R, G, B are out of the range of the adjusted values based on the target color space which the user selects.
- Page 28 Extreme Super Bright Screen OBM-H120 Professional Video Monitor Wave/Vector Scope Size Adjustable Waveform & Vector Scope Posi on Changeable The posi on of Waveform and Vectro Scope can be changed among The image size of Wave/Vector Scope Le Top, Right Top, Right Bo om, Le Bo om.
- Page 29 Extreme Super Bright Screen OBM-H120 Professional Video Monitor Password Lock for User Preset When mul ple users share the same monitor, each user can register his/her own password for color temperature and user preset data. This ensures the users correctly recalls their preset data, and keeps preset informa on safe from unauthorized use.
- Page 30 Extreme Super Bright Screen OBM-H120 Professional Video Monitor Fast Mode This func on allows the total latency to become nearly the zero delay, from the receipt of the signal to the on-screen display. Input Signal Fast Mode On Fast Mode Off...
-
Page 31: Product Specifications
Extreme Super Bright Screen OBM-H120 Professional Video Monitor 9. Product Specifications OBM-H120 ITEM 2 x 3G/HD/SD-SDI BNC (SDI) 1 x HDMI 1.3a HDMI Input 3 x Analog(YPbPr) BNC (YPbPr) 1 x Composite BNC (CVBS) 2 x 3G/HD/SD-SDI Output BNC (SDI) 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/50) -
Page 32: Dimensions
--Main Body : 2.4kg / 5.29lbs (With Stand : 3.2kg / 7.05lbs) 41mm / 1.61inch 304.5mm / 11.98inch 348.4mm / 13.71inch 110mm / 4.33inch 208, Building A, Samsong Techno Valley, 140, Tongil-ro, Deogyang-gu, Goyang-si, Gyeonggi-do, Korea, 10594 Tel : +82.2.354.6055 / Fax : +82.2.354.6056 E-mail : sales@postium.com www.postium.com...
