Postium OBM-N170G Operational Instructions

Professional video monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
OBM-N/L/R Series
Professional Video Monitor
Operational Instructions
OBM-N170G
OBM-N180
OBM-N210
OBM-N240
OBM-N310
OBM-N420
OBM-N460
OBM-N550
OBM-L180
OBM-R210
OBM-H210
Ver23.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OBM-N170G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Postium OBM-N170G

Summary of Contents for Postium OBM-N170G

  • Page 1 User Manual OBM-N/L/R Series Professional Video Monitor Operational Instructions OBM-N170G OBM-N180 OBM-N210 OBM-N240 OBM-N310 OBM-N420 OBM-N460 OBM-N550 OBM-L180 OBM-R210 OBM-H210 Ver23.1...

  • Page 2: Table Of Contents

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Table of Contents 1. Precaution 2. Main Features 3. Location and Function of Parts and Controls Front Panel Rear Panel 4. Using the Menu 5. Adjustment Using the Menus 6. OSD Menu Operations Status Menu Color Temp/Color Space/Gamma Menu Camera Assist Menu...

  • Page 3: Precaution

    Always use set voltage. AC 100 ~ 230V, 50/60Hz DC 12V(OBM-N170G/N180/N210/N240/L180/R210/H210) or DC 24V(OBM-N310/N420) All these instruc ons should be read and understood before opera ng the unit. If liquid is spilled on or impacts this product, please disconnect the product immediately and seek profession- al help before con nued use.
  • Page 4 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Do not a empt to service the product yourself. Removing covers can expose you to high voltage and other dangerous condi ons. Request a qualified service person to perform servicing. When the product needs replacement parts, make sure that the service person uses replacement parts specified by the manufacturer, or those with the same characteris cs and performance as the original parts.

  • Page 5: Main Features

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality 2. Main Features The OBM N series offers the superior picture quality and wide viewing angle, and includes an array of professional features and the advanced audio & video signal analysis func ons including Waveform, Vector Scope, Audio Level Meter, IMD, Camera Log Selec on, Custom 3D LUT Import, Focus Assist, etc.

  • Page 6: Location And Function Of Parts And Controls

    Front Panel (OBM-N180/N210/N240/N310/N420/N460/N550/H210) A : Input select Bu ons/Lamp Press to monitor the signal input to each connector. (OBM-L180) (OBM-R210) (OBM-N170G) -(OBM-N170G/N180/N210/N240/N310/N420/N460/N550/H210) [SDI-A] Bu on/Lamp - Press the bu on to select 3G SDI-1 input. [SDI-B] Bu on/Lamp - Press the bu on to select 3G SDI-2 input.
  • Page 7 - When the on-screen menu is not displayed, if this bu on is pressed the main menu is displayed. When the menu is displayed, press the bu on to return to the previous menu. -(OBM-N170G/N180/N210/N240/N310/N420/N460/N550/H210) [SEL/VOL] knob (Menu selec on control) - When the menu is displayed, turn the knob to select a menu item or a se ng value, and then press the knob to confirm the se ng.
  • Page 8 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality (OBM-L180/R210) [UP] Bu on - When the menu is displayed, press the bu on to select a menu item or increase the value. [DOWN] Bu on - Press the bu on to select the Aspect Ra o of the signal. - When the menu is displayed, press the bu on to select a menu item or decrease the value.

  • Page 9: Rear Panel

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Rear Panel -(OBM-N170G/N180/N210/N240/N310//N420/N460/N550/R210/H210) -(OBM-L180)
  • Page 10 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality A : SDI IN (SDI Input) connectors (BNC) Input connectors for SDI signals. B : SDI OUT (SDI Output) connectors (BNC) Output connectors for SDI signals. Each connector outputs the signal which is input to the corresponding SDI IN connector. **Note - Output is ac vated only when the power is on.
  • Page 11 J : DC IN terminal Connects the DC power supply to the monitor. - OBM-N170G / N180 / N210 / N240 / L180 / R210 : 12V - OBM-N310 / N420 /H210 : 24V Make sure to use DC 12V power supply for OBM-N170/N180/N210/N240/L180/R210 and DC 24V power supply for OBM-N310 / N420.

  • Page 12: Using The Menu

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality 4. Using the Menu This monitor is equipped with an OSD menu to make various adjustments and se ngs such as picture control, input se ng, set se ng change, etc. 2. Turn SEL/VOL knob to select a menu, 1.

  • Page 13: Adjustment Using The Menus

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality 5. Adjustment Using the Menus The OSD menu of this monitor consists of the following items. Status menu (To indicate the current se ngs) Camera Assist menu Format Zebra & False Color Color Temp Zebra Level Adjustment Brightness...
  • Page 14 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality User Configura on menu Closed Cap on Se ng Closed Cap on Load User Preset Se ng Type Save Func on Bu on Se ng F1 Bu on System Se ng Internal Pa ern F2 Bu on Key LED F3 Bu on...

  • Page 15: Osd Menu Operations

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality 6. OSD Menu Operations Status Menu The Status menu displays the current status of the Page 3/4 monitor. The following items are displayed. Page 1/4 SDI Input Iden fier SDI Payload ID Sampling Picture Rate Format...

  • Page 16: Color Temp/Color Space/Gamma Menu

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Color Temp/Color Space/Gamma Menu These menus are used for adjus ng or se ng the color Page 2/2 temperature, color space or gamma of the picture. Page 1/2 Color Space - Selects the color space between [ITU-R BT.709], [Na ve].

  • Page 17: Camera Assist Menu

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Color Temp/Color Space/Gamma Menu Camera Assist Menu Page 1/3 Camera Log Selects a camera log for the input signal. [Off]: Sets off the camera log. [Default]: The log which is selected in [Default Log Sel.] menu is applied.
  • Page 18 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Camera Assist Menu Page 3/3 False Color Comparison - Allows the user to divide the picture side by side and compare the original image on the le half and the False Color image on the right half.

  • Page 19: User Configuration Menu

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality User Configuration Menu User Configura on consists of the adjustment Page 2/8 menus such as[User Preset],[Func on Bu on Se ng],[Input Se ng],[Output Se ng],[Speaker Out / Audio Level Meter Se ng],[Marker Se ng],[W- FM/Vector Se ng], [Closed Cap on Se ng], [System Se ng].
  • Page 20 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality User Configuration Menu Speaker Out / Audio Level Meter Se ng Page 4/8 - Selects the audio channel of the SDI & HDMI input signal. SDI : Le Speaker Out / Right Speaker Out - Selects the embedded audio channel for the le and right audio out of the Headphone jack on the front panel of the monitor.
  • Page 21 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality User Configuration Menu Page 6/8 Page 5/8 WFM/Vector Se ng Marker Se ng 2/2 WFM/Vector Custom H1 - Select [On] to display the [WFM/Vector] and [Off] - Adjust the first line of the panel height. not to display.
  • Page 22 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality User Configuration Menu Page 7/8 Key LED Sets On to turn on the LED of the keys, and sets Off to turn off the LED of the keys. OSD Time Adjusts the display me of the OSD menu. [10 Sec.]: The OSD menu will be disappeared a er 10 seconds.

  • Page 23: Remote Menu

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Page 2/3 Remote Menu Page 1/3 Monitor ID Sets the ID of the monitor to control the monitor through Serial Remote or Network. Parallel Remote Selects the Parallel Remote connector pins for In-Monitor Display Se ng which you want to change the func on.

  • Page 24: Security Menu

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Security Menu Remote Menu Page 3/3 Password Lock -This func on allows the user to protect the se ng values through password. -When the Password lock is applied, the func ons and the se ng values can be changed, but they are not saved.

  • Page 25: Available Signal Formats

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality 7. Available Signal Formats This monitor is applicable to the following signal formats HD-SDI Signal System Signal Format 1920x1080 / 4:2:2 YCbCr 10bit 23.98, 24, 25, 29.97, 30p/Psf, 50, 59.94, 60i 2048 x 1080 / 4:2:2 YCbCr 10bit 23.98, 24, 25, 29.97, 30p/Psf 1280x 720 /...

  • Page 26: Key Functions

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality 8. Key Functions Focus Assist High Dynamic Range(HDR) Display Func on The OBM N series provides the func on to display the This func on controls the aperture level of a video High Dynamic Range footage.
  • Page 27 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Black Stretch The Black Stretch increases the visibility of subjects in dark areas, not degrading image quality in bright areas. This mode can be used to increase shadow detail without changing the absolute black level, and without affec ng mid-tones. Black Stretch Off...
  • Page 28 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Gamut Error Zebra pa ern or Color is displayed on the por on whose Y, Cb, Cr and R, G, B are out of the range of the adjusted values based on the target color space which the user selects. The default values of Y Maximum/Minimum, Chroma Maximum/Minimum, RGB Maximum/Minimum are in compliance with EBU R 103 standard.
  • Page 29 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Waveform & Vector Scope Posi on Changeable The posi on of Waveform and Vectro Scope can be changed among Le Top, Right Top, Right Bo om, Le Bo om. HDR Waveform When HDR more is set on, HDR Waveform is displayed on screen. HDR Mode + HDR Waveform HDR Waveform SDR Mode + SDR Waveform...
  • Page 30 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality Custom 3D LUT File Import The OBM series allow the user to import 3D Look-up Table for accurate and consistent color matching between indivisual displays. as well as using customized ‘looks’ that have been createcl by 3rd party color-grading applica ons.

  • Page 31: Product Specifications

    Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality 9. Product Specifications OBM-N170G / N180 / L180 OBM-N170G OBM-N180 OBM-L180 ITEM 3G/HD/SD-SDI-1/2 2 x BNC HDMI 1.3a 1 x HDMI HDMI 1.3a Input 3 x BNC Analog(YPbPr) 1 x BNC Composite (CVBS)
  • Page 32 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality OBM-N210 / N240 OBM-N210 OBM-N240 ITEM 2 x BNC 3G/HD/SD-SDI-1/2 1 x HDMI HDMI 1.3a Input 3 x BNC (YPbPr) Analog(YPbPr) 1 x BNC (CVBS) Composite 1 x DVI DVI-D Output 2 x BNC 3G/HD/SD-SDI-1/2 SMPTE ST 425-AB 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/50)
  • Page 33 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality OBM-N310 / N420 OBM-N310 OBM-N420 ITEM 3G/HD/SD-SDI-1/2 2 x BNC 1 x HDMI HDMI 1.3a Input 3 x BNC (YPbPr) Analog(YPbPr) 1 x BNC (CVBS) Composite 1 x DVI DVI-D Output 2 x BNC 3G/HD/SD-SDI-1/2 SMPTE ST 425-AB 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/50)
  • Page 34 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality OBM-N460 / N550 OBM-N460 OBM-N550 ITEM 3G/HD/SD-SDI-1/2 2 x BNC 1 x HDMI HDMI 1.3a Input 3 x BNC (YPbPr) Analog(YPbPr) 1 x BNC (CVBS) Composite 1 x DVI DVI-D Output 2 x BNC 3G/HD/SD-SDI-1/2 SMPTE ST 425-AB 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/50)
  • Page 35 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality OBM-R210 OBM-R210 ITEM 2 x 3G/HD/SD-SDI-1/2 BNC (SDI) 1 x HDMI 1.3a HDMI 3 x Analog(YPbPr) BNC (YPbPr) Input 1 x Composite BNC (CVBS) 1 x DVI-D Output 2 x 3G/HD/SD-SDI-1/2 BNC (SDI) SMPTE ST 425-AB 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF 29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/50)
  • Page 36 Professional Video Monitor OBM-N/L/R/H Series Outstanding Picture Quality OBM-H210 ITEM OBM-H210 2 x 3G/HD/SD-SDI-1/2 BNC (SDI) 1 x HDMI 1.3a HDMI 3 x Analog(YPbPr) BNC (YPbPr) Input 1 x Composite BNC (CVBS) 1 x DVI-D Output 2 x 3G/HD/SD-SDI-1/2 BNC (SDI) SMPTE ST 425-AB 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF 29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/50)
  • Page 37 OBM-N/L/R/H Series 208, Building A, Samsong Techno Valley, 140, Tongil-ro, Deogyang-gu, Goyang-si, Gyeonggi-do, Korea, 10594 Tel : +82.2.354.6055 / Fax : +82.2.354.6056 E-mail : sales@postium.com www.postium.com...
