2.2

AiMC-2000 I/O Indication

2.2.1

Front I/O Indication

HDD LED
Power
Switch
RS-232(2)
2.3

I/O Connectors

2.3.1

DC-IN Power connector (DCIN1)

Pin
1
2
2.3.2

HDMI A type connector (HDMI1)

Pin
1
3
5
7
9
11
13
15
17
19
USB2.0
USB3.0
Line out USB2.0
USB2.0
Line in LAN2
LAN1
4*USB2.0
RS-232(4)
RS-232(3)
Signal
GND
+12V_DCIN
Signal
TMDS Data2+
TMDS Data2–
GND
TMDS Data0+
TMDS Data0–
GND
NC
DDC_CLK
GND
Hot Plug Detect
Remote
PS/2
Power
HDMI KB/MS
On/Off
VGA
RS-232(5) RS-232(6)
Pin Signal
2 GND
4 TMDS Data1+
6 TMDS Data1–
8 GND
10 TMDS Clock+
12 TMDS Clock-
14 NC
16 DDC_DATA
18 +5 V
9 AiMC-2000 User Manual
DC in
RS-232/422/485
(COM1)
