Table Of Contents; Important Safety Instruction - Powercom 425A/AP User Manual

EMC Statement ............................................................................................................... 1
French Safety Instruction..........................................................................................................1
1. IMPORTANT SAFETY INSTRUCTION ........................................................................ 2
2. Introduction ........................................................................................................... 3
3. Installation ............................................................................................................. 3
3.1 Rear panel view ..................................................................................................... 3
3.2 Connection to Main and Load ............................................................................... 3
4. Operation ............................................................................................................... 4
4.1 General Description .............................................................................................. 4
4.2 System Configuration ............................................................................................ 4
4.3 UPS Control ........................................................................................................... 4
4.4 UPS Configuration ................................................................................................. 5
5. UPS Monitoring Connection ................................................................................... 5
6. Maintenance .......................................................................................................... 5
6.1 Transportation ...................................................................................................... 5
6.2 Storage .................................................................................................................. 5
6.3 Operation .............................................................................................................. 5
6.4 Battery .................................................................................................................. 5
6.4.1 Maintenance .......................................................................................... 5
6.4.2 Replacement .......................................................................................... 6
APP-A. Troubleshooting .................................................................................................. 6
APP-B Technical Specifications ....................................................................................... 7
 This Manual Contains Important Instructions that should be followed during Installation and
Maintenance of the UPS
 WARNING: Manual contains important instructions of UPS and batteries during installation and
maintenance. Follow this instruction at all time.
 WARNING: It is recommended to install UPS in an ANSI/NFPA75 room in which temperature and humidity
are controlled and free from electrically conductive particles. DO NOT expose UPS to direct sunlight or
high heat source; DO NOT block off ventilation opening around the housing.
 CAUTION: Before conducting maintenance, repair, or shipment, please turn off everything completely
and disconnect them.
 CAUTION: The UPS is NOT applicable for any inductive loads such as motors or domestic appliances like
hairdryers, speakers, and fluorescent lamps.
 CAUTION: All interconnection and power cable should be connected ONLY AFTER the UPS shut down and
disconnected from main.
 CAUTION: Only use No.26 AWG or larger certified cables to connect UPS and device.
 CAUTION: DO NOT unplug UPS from main power during operation or protective ground will fail. DO NOT
disconnect battery under load or shut down may occur.
 CAUTION: Ensure the total leakage current of UPS and the connected equipment under 3.5mA.
 CAUTION: Ensure UPS connects to grounded main power with a fuse or circuit breaker protection.
 CAUTION: Dangerous amount of voltage might still exist even the UPS disconnects from the main power
since residual voltage exists due to battery supply.
 CAUTION: Beware of all the details on the cautionary sticker located on UPS.
 CAUTION (No user-serviceable parts): Do not attempt to remove the unit's cover, no user-serviceable
parts inside. Please refer all service to qualified service technicians.
