AGA PRO+ APRO36DF User Manual & Installation & Service Instructions

AGA PRO+ APRO36DF User Manual & Installation & Service Instructions

Dual fuel
Hide thumbs Also See for PRO+ APRO36DF:
Table of Contents

Advertisement

Dual Fuel

User Guide

&
Installation & Service Instructions
U110054 - 02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO+ APRO36DF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AGA PRO+ APRO36DF

  • Page 1: User Guide

    ™ Dual Fuel User Guide & Installation & Service Instructions U110054 - 02...
  • Page 2: Table Of Contents

    Contents Important Safety Information In Case of Fire To Prevent Fire or Smoke Damage Wear Suitable Clothing Use Only Dry Potholders or Oven Gloves Important Safety Notice and Warning Proper Installation Conversion User Servicing Cooktop burners Use the Right Size Pan Ovens Placement of Oven Racks General Safety Instructions...
  • Page 3: Important Safety Information

    1. Important Safety Information Read all instructions before using this appliance. Save these instructions for future reference. Have your appliance properly installed and grounded by a qualified technician in accordance with the National Electrical Code ANSI/NFPA No. 70 – latest edition, and local code requirements.
  • Page 4: Wear Suitable Clothing

    To avoid risk of electrical shock, personal injury, or death, make sure your range has been properly grounded and always disconnect it from the main power supply before servicing. DO NOT touch cook top burners or areas near  burners. Gas burners may be hot even if they have been off for some time.
  • Page 5: Use The Right Size Pan

    Use the Right Size Pan This appliance is equipped with burners of different sizes. Use utensils with flat bottoms. Do not use unstable pans and position the handles away from the edge of the cooktop. Make sure the flames are under the pans. It is not safe to let the flames burn up the sides of the pan;...
  • Page 6 Always keep combustible wall coverings or curtains etc. a safe distance away from your range. DO NOT spray aerosols in the vicinity of the range  while it is in use. Do not store or use combustible materials, or flammable liquids in the vicinity of this appliance.
  • Page 7: Range Overview

    2. Range Overview The dual fuel single cavity range cooker (Fig.2-1) has the following features: 5 hotplate burners including a wok burner A control panel incorporating a timer A multi-function oven A storage drawer Cooktop Burners Note: Before using the cooktop make sure all burners are in place and all the grates on the range are properly placed.
  • Page 8 Fig.2-3 ArtNo.272-0002 Prof+ pyro US - Control to low Fig.2-4 ArtNo.311-0001 Right pans gas Fig.2-5 Fig.2-6 ArtNo.311-0002 Pan with rim Art No. 311-0003 Simmer aids ArtNo.311-0004 Tipping wok Fig.2-7 The igniter should spark and light the gas. Keep holding the knob pressed in to let the gas through to the burner for about ten seconds.
  • Page 9: Wok Burner

    Wok Burner The wok burner is designed to provide even heat over a large area. It is ideal for large pans and stir-frying (Fig.2-8). For heating smaller pans, the aforementioned hotplate burners may be more efficient. You can remove the burner parts for cleaning; see ‘Cleaning your cooker’.
  • Page 10: Operating The Oven

    Fig.2-10 ArtNo.272-0003 Prof+ pyro US - MF oven controls (2) Function selector ArtNo.272-0004 Prof+ pyro US - MF oven - Prof+ pyro US - MF oven - Function setting Fig.2-11 Fig.2-13 ArtNo.272-0006 Prof+ pyro - MF oven annotated A - Thaw & serve, B - Convection oven, C - Convection broiling, D - Fan assisted oven, E - Conventional oven, F - Browning element, G - Warming, H - Self clean Fig.2-14...
  • Page 11 Rack levels 5 and 6 should be used depending on the size of the food being cooked. Fan Assisted Oven This function operates the fans, circulating air heated by the elements at the top and the base of the oven (Fig.2-17).
  • Page 12: Sabbath Mode

    Fig.2-21 ArtNo.281-0150 - Oven Divider Fig.2-22 ArtNo.062-0005 - Removing the divider (wrong) Fig.2-23 ArtNo.062-0004 - Removing the divider (right) Sabbath Mode Choose conventional oven or warming oven modes as best suits you cooking needs. Set the desired temperature with temperature selector. The unit will not shut off until the function selector is turned OFF.
  • Page 13: The Clock

    The Clock You can use the 6-button timer (Fig.2-24) to turn the oven on and off. The clock must be set to the time of day before the oven will work. To set the time of day Press and hold both the [C] and [D] buttons as shown in Fig.2-25.
  • Page 14: Key Lock

    Fig.2-34 ArtNo.302-0015 - Activating the key lock 1 pyro Fig.2-36 ArtNo.302-0010 - Activating the key lock 3 Fig.2-37 ArtNo.302-0017 - 6BC Deactivating the key lock 1 Pyro Fig.2-38 ArtNo.302-0018 - Deactivating the key lock 2 pyro AUTO is showing, you want to reset to manual Fig.2-35 cooking When cancelling an automatic setting, any cooking time...
  • Page 15: Accessories

    Accessories Oven racks Each range is supplied with the following: 2 full width racks (Fig.2-39) 1 telescopic rack with runners (Fig.2-40) 2 broiler pans with grids (Fig.2-41) 3 energy saving racks (Fig.2-42) 2 sets of side rack supports (Fig.2-43) 1 energy saving divider (Fig.2-44) The oven shelves are retained when pulled forward but can be easily removed and refitted.
  • Page 16: Oven Light

    Fig.2-50 ArtNo.320-0017 Main oven light Fig.2-51 ArtNo.281-0138 - Drawer pulled out Fig.2-52 Fig.2-53 Make sure the inner rail is forwards Fig.2-54 Drawer Oven Light Press the button to turn on the oven lights (Fig.2-50). If one of the oven lights fail, turn off the range circuit breaker before you change the bulb.
  • Page 17: Cooking Tips

    3. Cooking Tips Cooking with a Multi-function Oven Remember: not all modes are suitable for all food types. The oven cooking times given are intended for a guide only. Tips on Cooking with the Timer If you want to cook more than one dish, choose dishes that require approximately the same cooking time.
  • Page 18: Cooking Table

    4. Cooking Table The oven control settings and cooking times given in the table below are intended to be used AS A GUIDE ONLY. Individual tastes may require the temperature to be altered to provide a preferred result. Food is cooked at lower temperature in a fan oven than in a conventional oven. When using recipes, reduce the fan oven temperature by 25°F (10°C) and the cooking time by 5-10 minutes.
  • Page 19: Troubleshooting

    5. Troubleshooting Cooktop ignition or cooktop burners faulty Is the power on? Are the sparker (ignition electrode) or burner holes blocked by debris? Are the burner heads correctly located? See the section entitled ‘Cleaning’. Remember that each cooktop burner has a special safety device that stops the flow of gas if the flame goes out.
  • Page 20 Fig.5-1 ArtNo.324-0005 Oven light bulb Fig.5-2 The timed oven is not coming on when automatic cooking Has the oven knob been left in the OFF position by mistake? Is the oven locked (see above)? Oven temperature getting hotter as the range gets older If turning the knob down has not worked or only worked for a short time then you may need a new thermostat.
  • Page 21: Cleaning Your Range

    6. Cleaning Your Range Essential Information Before thorough cleaning, turn off the circuit breaker. Allow the range to cool. After cleaning, remember to switch on the circuit breaker and reset the clock before re-using the range. Never use paint solvents, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt.
  • Page 22: Main Top

    Fig.6-5 ArtNo.272-0015 - 90DF - Pro+ - Removing the outer door panel Fig.6-6 Fig.6-7 Fig.6-8 Main Top Lift away pots or pans from the main top. Remove the grates from the spillage area and carefully place in a sink of warm soapy water.
  • Page 23 To remove and refit the telescopic rack and runners Slide the rack out on the runners. While holding one of the runners securely, carefully lift the rear of the rack upwards: the rack will spring clear of the central restraining tab. Repeat for the opposite side of the rack.
  • Page 24: Cleaning Table

    Door inner Glass Hot soapy water and soft cloth. Mildly abrasive cleaner with a soft cloth. ArtNo.050-0016 - Cleaning table AGA USA Outer door Painted enamel Multi-surface cleaner, soft cloth. and drawer or stainless steel Table 6-2...
  • Page 25 If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. WHAT TO DO IF YOU SMELL GAS Do not try to light any appliance.
  • Page 26: Installation

    Check the appliance is electrically safe and gas sound when you have finished. 7. Installation Regulations Installation of this range must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA.54, latest edition. In Canada, installation must conform with the current Natural Gas Installation Code, CAN/CGA-B149.1 or the current Propane Installation Code, CAN/CGA-B149.2, and with local...
  • Page 27 Check the appliance is electrically safe and gas sound when you have finished. This will allow the range to be moved for cleaning or servicing. Also, make sure your floor covering will withstand 180°F (80°C); see the ‘Installation Safety Instructions’ section. Make sure the wall coverings around your range can withstand the heat generated, up to 200°F (90°C), by the range;...
  • Page 28: Positioning The Range

    Check the appliance is electrically safe and gas sound when you have finished. Fig.7-1 Min 35½” (90cm) - 36“ (91cm) For Canada, min 363/8” (92.5cm) Min 31½” (80cm) between the top of the cooktop Maximum 13” and a horizontal combustible surface Min 35 15⁄16”...
  • Page 29: Moving The Range

    Check the appliance is electrically safe and gas sound when you have finished. Moving the Range The range is very heavy. Take great care.  We recommend two people maneuver the range. Ensure that the floor covering is firmly attached or removed to prevent it being disturbed when moving the range around.
  • Page 30: Completing The Move

    Check the appliance is electrically safe and gas sound when you have finished. Fig.7-8 ArtNo.010-0009 Pushing the cooker Fig.7-9 INSTALLATION Completing the Move Grip under the fascia panel and lift the front of the range slightly. Carefully position the range close to its final position, leaving just enough space to get behind it (Fig.7-8).
  • Page 31: Anti-Tip Device

    Check the appliance is electrically safe and gas sound when you have finished. Anti-Tip Device WARNING!  The range MUST be secured by the anti-tip bracket supplied. Unless properly installed, the range could be tipped by leaning on the door and injury might result from spilled hot liquids or from the range itself.
  • Page 32: Electrical Connection

    Check the appliance is electrically safe and gas sound when you have finished. Fig.7-16 16” (41cm) ArtNo.281-0013 - Albertine SC - Electrical location 12” (30cm) min Fig.7-17 ArtNo.281-0008 - 900SC - Electrical connection cover INSTALLATION Electrical Connection When installed the range must be electrically grounded in accordance with local codes or;...
  • Page 33 Check the appliance is electrically safe and gas sound when you have finished. 4-Wire Conduit Installation Disconnect the supplied power cord from the terminal block and ground post. Keep the terminal block parts; you will need them. Remove the strain relief clamp from the power cord and remove the power cord and strain relief clamp from the mounting bracket (Fig.7-18).
  • Page 34 Check the appliance is electrically safe and gas sound when you have finished. Fig.7-24 ArtNo.280-0039 Reducer Plate Fig.7-25 ArtNo.280-0043 3-Wire conduit fitting Fig.7-26 Black White ArtNo.280-0083 - 3-Wire conduit connection INSTALLATION 3-Wire Conduit Installation Disconnect the supplied power cord from the terminal block and ground post.
  • Page 35: Gas Connection

    Check the appliance is electrically safe and gas sound when you have finished. Gas Connection Installation of this range MUST conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1-latest edition. In Canada The range MUST be installed in accordance with the current CGA Standard CAN/CGA-B149 –...
  • Page 36: Flexible Connector

    Check the appliance is electrically safe and gas sound when you have finished. Fig.7-30 Flexible connector Adaptor ArtNo.280-0037 Gas Connection ½“ or ¾” gas pipe Gas supply Gas shut-off valve Adaptor INSTALLATION Connect the Range to the Gas Supply Shut off the main gas supply valve before disconnecting the Appliance old range and leave it off until the new hookup has been gas inlet...
  • Page 37: Seal The Openings

    Check the appliance is electrically safe and gas sound when you have finished. Seal the Openings Seal any openings in the wall behind the range and in the floor under the range when hookups are completed. IMPORTANT: When all connections are completed make sure the flow of combustion and ventilation air to the range is unobstructed.
  • Page 38: Range Operational Checks

    Check the appliance is electrically safe and gas sound when you have finished. Range Operational Checks Oven Check Turn on the oven and check that the oven fans start to turn and that the oven starts to heat up. Turn off the oven. Oven Light Check Press the oven light switch and check that the lights are working.
  • Page 39: Conversion To Another Gas Important

    Check the appliance is electrically safe and gas sound when you have finished. 8. Conversion to Another Gas Important! • Observe all governing codes and ordinances. • The range must be properly grounded. • Save these instructions for the local electrical inspector’s use.
  • Page 40: Gas Regulator

    Check the appliance is electrically safe and gas sound when you have finished. ArtNo.0102-0001 - Unscrewing the control valve bypass screw Fig.8-4 Natural Gas Wok burner Large burner Medium burner Small burner Table 8-2 Fig.8-6 Fig.8-7 Type 1 ArtNo.102-0005 - Gas regulator types Fig.8-8 ArtNo.103-0006 - Maxitrol cap &...
  • Page 41: Stick On Label

    Check the appliance is electrically safe and gas sound when you have finished. Stick on label Stick the “NOW ADJUSTED FOR LP GAS” label next to the ratings label inside the drawer cavity to indicate the gas the appliance is now set for (Fig.8-12). Pressure Testing Connect the appliance to the gas supply.
  • Page 42: Refitting The Grille And Drawer

    Check the appliance is electrically safe and gas sound when you have finished. Fig.8-14 Fig.8-15 Make sure the inner rail is forwards Fig.8-16 Drawer INSTALLATION Refitting the Grille and Drawer Refitting the Flue Grille Locate the grille onto the flue and secure to the cooktop with the 4 screws supplied (Fig.8-14).
  • Page 43: Circuit Diagram

    9. Circuit Diagram A2/B1 B2 Code Description MF oven master switch MF oven drone switch Oven thermostat Oven front switch Right-hand oven base element Right-hand oven top outer element Right-hand oven top inner element Right-hand oven fan element Right-hand oven fan Cooling fan (2 speed) Left-hand oven base element Left-hand oven top outer element...
  • Page 44: Technical Data

    10. Technical Data INSTALLER: Please leave these instructions with the user. RATING PLATE LOCATION: Inside base drawer of cavity. Remove the drawer (see Overview > Storage for details). COUNTRY OF DESTINATION: USA/Canada Connections Electric Dimensions Overall height Overall width Overall depth Minimum space for cooktop Ratings Oven...
  • Page 47 AGA warrants the oven heating elements against defects in material or workmanship for an additional two years. These parts will be repaired or replaced at the option of Aga without charge, but you pay for labor and transportation subject to the terms and conditions set out below.
  • Page 48 1050 Fountain St. N., Cambridge, Ontario, Canada N3H 4R7 Business (519) 650-5775 or Fax (519) 650-3773 Toll free phone 1-877-650-5775 Toll free fax 1-800-327-5609 www.aga-ranges.com ArtNo.000-0003 CE logo...
