  • Page 1 B-5360 ­ Hardware and Install Manual ­ Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 2: Table Of Contents

    How to Insert the Memory Card ........... 20 ­ How to Remove the Memory Card..........20 ­ How to Adjust the Fisheye View Orientation [B-5360] ....21 ­ How to Connect Audio In Device........... 22 ­ How to Replace the Dome Cover ........... 23 ­...
  • Page 3 B-5360 Hardware and Install Manual Configure the IP Addresses ............25 ­ Using DHCP Server to Assign IP Addresses........ 25 ­ Using the Default Camera IP Address.......... 27 ­ Access the Camera................. 29 ­ Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 4: Precautions

    B-5360 Hardware and Install Manual Precautions Read these instructions Read all the safety and operating instructions before using this product. Heed all warnings Adhere to all the warnings on the product and in the instruction manual. Failure to follow the safety instructions given may directly endanger people, cause damage to the system or to other equipment.
  • Page 5 B-5360 Hardware and Install Manual Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 6: Safety Instructions

    B-5360 Hardware and Install Manual Safety Instructions Cleaning Disconnect this product from the power supply before cleaning. Accessories and Repair Parts Use only the accessories and repair parts recommended by the manufacturer. Using other attachments not recommended by the manufacturer may cause hazards.

  • Page 7: Introduction

    B-5360 Hardware and Install Manual Introduction Package Contents Check if the camera package comes with the following items: Camera Drill Template B 5360 Drill Template Hexagon Screwdriver Dome Cover Tab Screw Kit Quick Installation Guide IMPORTANT: When the camera is taken out from the box, the lens cover is covered by a thin film.
  • Page 8 B-5360 Hardware and Install Manual B-5360 ­ Item Description System LEDs Indicates the camera status: Amber LED: Blinks when network activity is in progress.  Blue LED: Lights up when the camera is powered up and  goes off again after the boot up process is complete.

  • Page 9: Mounting Options

    B-5360 Hardware and Install Manual Mounting Options Select the most suitable solution for your installation environment. The camera can be mounted by either of the following methods: Mount Types Accessories Surface Mount Suitable when mounting the camera directly on walls or ceilings without additional mounting accessories.

  • Page 10: Installation Procedures

    B-5360 Hardware and Install Manual Installation Procedures This section describes procedures in mounting the camera on a flat surface. ­ NOTE: The camera images on this documentation are for reference only and may be different ­ from the actual camera. Step 1: Prepare for Installation 1. ­...

  • Page 11: Step 2: Open The Dome Cover

    B-5360 Hardware and Install Manual Step 2: Open the Dome Cover 1. Loosen the three (3) screws using the bundled hex screwdriver. 2. Lift to remove the dome cover. NOTE: A desiccant bag is attached underneath the dome cover. DO NOT remove the desiccant bag to keep the camera interior parts dry.

  • Page 12: Step 3: Route The Cables

    B-5360 Hardware and Install Manual Step 3: Route the Cables Determine whether the cable will pass through a hole on the surface or be routed along the surface: If the cable will pass through a hole on the surface: 1. ­ Drill the hole for the cable on the surface.

  • Page 13: Step 4: Install The Camera

    B-5360 Hardware and Install Manual If the cable will be routed along the surface Route the camera cable through the gap on the camera cover. Step 4: Install the Camera 1. ­ If necessary, insert a memory card into the memory card slot of the camera. See...

  • Page 14: Step 5: Waterproof The Cable Connection

    B-5360 Hardware and Install Manual Step 5: Waterproof the Cable Connection RJ-45 Ethernet Cable (B-5360) When using the RJ-45 Ethernet cable, follow the procedures below to waterproof the cable connection: 1. Detach the cable gland as shown below. Gland Body...
  • Page 15 B-5360 Hardware and Install Manual 4. Make sure the bundled rubber ring is completely aligned on the gap on the gland body. 5. Attach the gland body to the Ethernet port of the camera. IMPORTANT! Make sure the rubber ring is completely aligned and flat on the gland body to avoid possible water leakage.
  • Page 16 B-5360 Hardware and Install Manual 7. Insert the sealing rubber and claw into the cable gland body. 8. Attach the clamping nut to the cable gland body. Make sure the clamping nut is tightly secured and the rubber is squeezed in to avoid water leakage.

  • Page 17: Step 6: Connect To Network

    B-5360 Hardware and Install Manual Step 6: Connect to Network Connect the other end of the network cable to a switch or injector. Then, connect the switch or injector to a network or PC and a power source. See Power-over-Ethernet (PoE) example connection diagram below.

  • Page 18: Step 8: Close The Dome Cover

    B-5360 Hardware and Install Manual Step 8: Close the Dome Cover 1. Align cable tab side of the dome cover to the direction of the network cable. Rubber NOTE: Make sure the rubber on the camera is positioned properly on its track as the dome cover is closed on the camera to ensure protection against water ingress.
  • Page 19 B-5360 Hardware and Install Manual Final installation should look similar to the illustration below. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 20: Other Adjustments And Accessories

    B-5360 Hardware and Install Manual Other Adjustments and Accessories How to Install / Remove the Memory Card NOTE: Supports microSDHC and microSDXC cards. How to Insert the Memory Card 1. Loosen the three (3) screws to remove the dome cover.

  • Page 21: How To Adjust The Fisheye View Orientation [B-5360]

    B-5360 Hardware and Install Manual How to Adjust the Fisheye View Orientation [B-5360] 1. Open the dome cover. 2. Loosen the three (3) screws securing the lens. 3. Turn the lens module to adjust the viewing orientation. The arrow on the lens indicates the top side orientation.

  • Page 22: How To Connect Audio In Device

    B-5360 Hardware and Install Manual How to Connect Audio In Device ­ The camera comes with an audio jack where an audio input device, such as a microphone with a built-in amplifier, can be connected. The audio-in jack is covered by a rubber protection.

  • Page 23: How To Replace The Dome Cover

    B-5360 Hardware and Install Manual How to Replace the Dome Cover For more discrete surveillance needs, the pre-installed dome cover can be replaced with a smoked, vandal proof dome cover. The smoked dome cover is an optiona accessory; contact your sales agent to purchase.
  • Page 24 B-5360 Hardware and Install Manual 4. Remove the black rubber from the transparent dome cover and place the black rubber to the replacement dome cover. 5. Install the replacement dome cover and then the bracket. 6. Align the screw holes and secure the six (6) screws.

  • Page 25: Accessing The Camera

    B-5360 Hardware and Install Manual Accessing the Camera Configure the IP Addresses In order to be able to communicate with the camera from your PC, both the camera and the PC have to be within the same network segment. In most cases, it means that they both should have very similar IP addresses, where only the last number of the IP address is different from each other.
  • Page 26 B-5360 Hardware and Install Manual You can quickly see the camera model in the list. Click on the IP address to automatically launch the default browser of the PC with the IP address of the target camera filled in the address bar of the browser already.

  • Page 27: Using The Default Camera Ip Address

    B-5360 Hardware and Install Manual Using the Default Camera IP Address If there is no DHCP server in the given network, the user may have to assign the IP addresses to both PC and camera manually to make sure they are in the same network segment.
  • Page 28 B-5360 Hardware and Install Manual Manually adjust the IP addresses of multiple cameras: If there are more than 1 camera to be used in the same local area network and there is no DHCP server to assign unique IP addresses to each of them, all of the cameras would then have the initial IP address of 192.168.0.100, which is not a proper situation for network devices –...

  • Page 29: Access The Camera

    B-5360 Hardware and Install Manual Access the Camera ­ Now that the camera and the PC are both having their unique IP addresses and are under the same network segment, it is possible to use the Web browser of the PC to access the camera.
  • Page 30 B-5360 Hardware and Install Manual The following examples in this manual are based on Internet Explorer browser in order to cover all functions of the camera. Assuming that the camera’s IP address is 192.168.0.100, you can access it by opening the Web browser and typing the following address into Web browser’s address bar:...
