B-38-V Bullet Camera
B-38-V
Hardware Manual
Ver. 2018/08/09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-38-V and is the answer not in the manual?

Questions and answers

Related Manuals for advidia B-38-V

Summary of Contents for advidia B-38-V

  • Page 1 B-38-V Bullet Camera B-38-V Hardware Manual Ver. 2018/08/09...

  • Page 2: Table Of Contents

    Step 5: Access the Camera Live View ....................12 Other Connections ............................ 13 Connecting a Power Adapter (Optional) ....................13 How to Connect Audio Input / Output Devices (Optional for B-38-V only) ..........13 Other Adjustments and Accessories ...................... 14 How to Reset the Camera (B-38-V ......................14 Accessing the Camera ..........................

  • Page 3: Precautions

    B-38-V Bullet Camera Hardware Manual Precautions Read these instructions You should read all the safety and operating instructions before using this product. Heed all warnings You must adhere to all the warnings on the product and in the instruction manual. Failure to follow the safety instruction given may directly endanger people, cause damage to the system or to other equipment.

  • Page 4: Safety Instructions

    B-38-V Bullet Camera Hardware Manual Safety Instructions Cleaning Disconnect this video product from the power supply before cleaning. Attachments Do not use attachments not recommended by the video product manufacturer as they may cause hazards. Water and Moisture Do not use this video product near water, for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool and the like.

  • Page 5: Introduction

    B-38-V Bullet Camera Hardware Manual Introduction List of Models This hardware manual contains the following models: 3MP Zoom Bullet with D/N, Adaptive IR, Extreme B-38-V WDR, SLLS, 4.3x Zoom lens...

  • Page 6: Package Contents

    B-38-V Bullet Camera Hardware Manual Package Contents Camera Mounting Screw Kit Camera Base Wrench Drill Template DI/DO Terminal block Warranty Card Quick Installation Guide...

  • Page 7: Physical Description

    B-38-V Bullet Camera Hardware Manual Physical Description B-38-V Side Back Item Description Ethernet Port Connects to a network using a standard Ethernet cable. Connects the camera to an external power adapter (not included). DC 12V Power Input for more Connecting a Power Adapter (Optional)
  • Page 8 B-38-V Bullet Camera Hardware Manual B-38-V Side Back Item Description This jack connects to an audio output device, such as a speaker. Audio Output See How to Connect Audio Input / Output Devices. Connects the camera to an external power adapter (not included).

  • Page 9: Mounting Options

    B-38-V Bullet Camera Hardware Manual Mounting Options There are several mounting options that you can use to install the camera. Select the most suitable solution for your installation environment. Mount Type Accessories Wall Suitable when mounting the camera directly on walls using the integrated bracket.

  • Page 10: Installation Procedures

    B-38-V Bullet Camera Hardware Manual Installation Procedures This section describes the procedures in installing the camera on a flat surface such as a hard or dropped ceiling and straight or tilted walls. Before installation, make sure the wall or ceiling can bear more than the weight of the camera.

  • Page 11: Step 2: Mount The Camera

    B-38-V Bullet Camera Hardware Manual Step 2: Mount the Camera 5. Mark the location of the screw holes based on the drill template included in the package. NOTE: Depending on the surface where you will install the camera, it may be necessary to drill three (3) holes and use the supplied screw tox.

  • Page 12: Step 3: Waterproof And Connect The Cable(S)

    B-38-V Bullet Camera Hardware Manual Step 3: Waterproof and Connect the Cable(s) The camera and the pre-installed network cable (pigtail) are resistant to salt, water, weak acid, alcohol, oil, grease and other common solvents. However, users must ensure that the cable connection and the network side cable itself are also protected from different environmental factors.

  • Page 13: Step 4: Connect To Network

    B-38-V Bullet Camera Hardware Manual Step 4: Connect to Network Connect the other end of the network cable to a switch or injector. Then, connect the switch or injector to a network, PC, and a power source. See Power-over-Ethernet (PoE) connection example below.

  • Page 14: Other Connections

    B-38-V Bullet Camera Hardware Manual Other Connections This section describes the procedures in preparing the external devices that you can connect to the camera. The camera supports DC12V power input, Digital Input and Output (DI/DO) and Audio Input and Output devices using the bundled terminal blocks. The use of these devices, however, is optional.

  • Page 15: Other Adjustments And Accessories

    B-38-V Bullet Camera Hardware Manual Other Adjustments and Accessories How to Reset the Camera The camera has a Reset button that can be used to restore the camera to its factory default settings when the need arises. The Reset button is used for the following purposes: The administrator’s password is forgotten and therefore the camera cannot be accessed...

  • Page 16: Accessing The Camera

    B-38-V Bullet Camera Hardware Manual Accessing the Camera Configure the IP Addresses In order to be able to communicate with the camera from your PC, both the camera and the PC have to be within the same network segment. In most cases, it means that they both should have very similar IP addresses, where only the last number of the IP address is different from each other.

  • Page 17: Use The Default Ip Address Of A Camera

    B-38-V Bullet Camera Hardware Manual When you launch IP Utility, the list of connected cameras in the network will be shown. See sample illustration below: You can quickly notice the camera model in the list. Click on the IP address to automatically launch the default browser of the PC with the IP address of the target camera filled in the address bar of the browser already.

  • Page 18: Manually Adjust The Ip Address Of The Pc

    B-38-V Bullet Camera Hardware Manual Manually adjust the IP address of the PC: In the following example, based on Windows 7, we will configure the IP address to 192.168.0.99 and set Subnet Mask to 255.255.255.0 by using the steps below:...

  • Page 19: Manually Adjust The Ip Addresses Of Multiple Cameras

    B-38-V Bullet Camera Hardware Manual Manually adjust the IP addresses of multiple cameras: If there are more than 1 camera to be used in the same local area network and there is no DHCP server to assign unique IP addresses to each of them, all of the cameras would then have the initial IP address of 192.168.0.100, which is not a proper situation for network devices –...

  • Page 20: Access The Camera

    B-38-V Bullet Camera Hardware Manual Access the Camera Now that the camera and the PC are both having their unique IP addresses and are under the same network segment, it is possible to use the Web browser of the PC to access the camera.
  • Page 21 B-38-V Bullet Camera Hardware Manual Upon successful connection to the camera, the user interface called Web Configurator would appear together with the login page. The HTTP port number was not added behind the IP address since the default HTTP port of the camera is 80, which can be omitted from the address for convenience.
  • Page 22 B-38-V Bullet Camera Hardware Manual...
