advidia B-57-V-2 Hardware Manual

Outdoor dome series
Hide thumbs
Table of Contents

Advertisement

Quick Links

B-57-V-2
Outdoor Dome Series
Hardware Manual
2019/06/03

Advertisement

Table of Contents
loading

Related Manuals for advidia B-57-V-2

Summary of Contents for advidia B-57-V-2

  • Page 1 B-57-V-2 Outdoor Dome Series Hardware Manual 2019/06/03...

  • Page 2: Table Of Contents

    Hardware Manual Table of Contents Precautions ............. 4 Safety Instructions ..................6 Introduction ............. 7 The List of Models ..................7 Package Contents ..................8 Physical Description .................. 9 Mounting Options ..................11 Installing the Camera on a Surface ..... 12 Step 1: Drill the Holes ................
  • Page 3 Hardware Manual How to Connect Audio Input / Output Devices ........30 How to Connect a Video Output Device ..........31 Other Accessories ..........32 How to Install / Remove the Memory Card ..........32 How to Insert the Memory Card ............. 32 How to Remove the Memory Card ............

  • Page 4: Precautions

    Hardware Manual Precautions Read these instructions You should read all the safety and operating instructions before using this product. Heed all warnings You must adhere to all the warnings on the product and in the instruction manual. Failure to follow the safety instruction given may directly endanger people, cause damage to the system or to other equipment.
  • Page 5 Hardware Manual Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.

  • Page 6: Safety Instructions

    Hardware Manual Safety Instructions Cleaning Disconnect this video product from the power supply before cleaning. Attachments Do not use attachments not recommended by the video product manufacturer as they may cause hazards. Do not use accessories not recommended by the manufacturer Install the PoE switch or injector and other devices that will be used with the camera in a dry place protected from weather.

  • Page 7: Introduction

    Hardware Manual Introduction The List of Models This hardware manual contains the following models: 12MP, Outdoor Zoom Dome, Day / Night, Adaptive IR, Advanced WDR, Superior Low Light Sensitivity, 3x Zoom Lens 5MP, Outdoor Zoom Dome, Day / Night, Adaptive IR, Advanced WDR, Superior Low Light Sensitivity, 4.3x Zoom Lens...

  • Page 8: Package Contents

    Hardware Manual Package Contents Camera Mounting Screws Allen Wrench Base Plate Conduit Gland Cable Gland Quick Installation Guide Drill Template Drill Template...

  • Page 9: Physical Description

    Hardware Manual Physical Description NOTE: The camera picture above is for reference only. Actual camera may slightly differ. Item Description System LED The amber LED lights up when the network Indicator connection is established. Input / Output Connector DC 12V Power In case the camera is connected to a non-PoE Input (Power over Ethernet) switch, use this connector to...
  • Page 10 Hardware Manual Item Description DC 5V Power Provides DC 5V power for digital output devices. Output Video Output Connects to a video output device, such as a camera installation kit, for camera adjustments on How to Connect a Video the installation site. See Output Device on page 31 for more information.

  • Page 11: Mounting Options

    Hardware Manual Mounting Options There are several mounting options that you can use to install the camera. Select the most suitable solution for your installation environment. Mount Types Accessories Surface Suitable when mounting the camera directly walls or ceilings Installing the Camera on a Mount without extra accessories.

  • Page 12: Installing The Camera On A Surface

    Hardware Manual Installing the Camera on a Surface This section describes the procedures in installing the camera on a flat surface such as a hard or dropped ceiling and straight or tilted walls. Before installation, make sure the wall or ceiling can bear more than the weight of the camera.

  • Page 13: Step 2: Prepare The Camera

    Hardware Manual Step 2: Prepare the Camera NOTE: To avoid scratches or leaving fingerprints on the dome cover, it is recommended to retain the plastic covering the dome cover until the camera is completely installed. However, the plastic has been removed on the pictures in this documentation to show clarity of the procedures being described.
  • Page 14 Hardware Manual 4. If necessary, insert a memory card with the metallic contacts facing the “MicroSD” label of the camera. Then push the card until it locks into place. 5. Prepare for cabling connections. If the cable will pass through the surface , follow the procedures in Option 1: Cable Passing Through the Surface and Bottom Cable Hole...
  • Page 15 Hardware Manual Option 2: Cable Passing Along the Surface and the Camera Side Cable Hole on page 20. To mount the camera, make sure to align the camera to the base plate then tighten the four (4) screws to complete installing the camera to the surface.

  • Page 16: Step 3: Waterproof The Cable Connection

    Hardware Manual Step 3: Waterproof the Cable Connection Depending on the installation environment, the cable can pass through the surface and go through the bottom hole of the camera or pass along the surface and through the side hole of the camera.
  • Page 17 Hardware Manual 3. Route the Ethernet cable without RJ-45 connector head through the surface. Then insert the Ethernet cable through the rubber. 4. Once the Ethernet cable passes through the camera hole, attach the RJ-45 connector (see How to Attach the RJ-45 Connector on page 33 for detailed information).
  • Page 18 Hardware Manual 7. Do the same procedures to connect other input/output devices to the camera. When done, seal the bottom cable hole(s) with silicon to protect it from water leak. NOTE: If no other devices will be connected, make sure that the other rubber is properly placed on the camera cable hole.
  • Page 19 Hardware Manual...

  • Page 20: Option 2: Cable Passing Along The Surface And The Camera Side Cable Hole

    Hardware Manual Option 2: Cable Passing Along the Surface and the Camera Side Cable Hole The camera comes with two (2) glands used to waterproof the side cable hole. Determine the type of waterproof solution that is applicable to your installation requirements and prepare the necessary accessories or purchase extra materials.
  • Page 21 Hardware Manual Waterproof Solution with Naked Cable This section describes the procedures in using the bundled cable gland and an exterior-grade Ethernet cable. 1. Disassemble the cable gland as shown below: Sealing Insert Body Clamping with Claw (with Washer) 2. Insert the clamping nut into the Ethernet cable. 3.
  • Page 22 Hardware Manual 4. Attach the cable gland body to the hole of the camera. 5. Insert the cable through the camera hole. 6. Connect the cable to the Ethernet port of the camera. 7. Insert the sealing insert with claw into the cable gland body and then attach the clamping nut to complete the cable solution.
  • Page 23 Hardware Manual Waterproof Solution with Conduit This section describes the procedures to waterproof the cabling connections using the bundled conduit gland and flexible conduit. This is the recommended if other input/output devices or an external power adapter will be connected to the camera or when an exterior-grade Ethernet cable is not available.
  • Page 24 Hardware Manual 3. Screw the conduit gland body to the conduit hole of the camera. 4. Pull the network cable through the flex conduit. If connecting other input/output devices or an external power adapter, pull the cables through the flex conduit without connectors. The terminal blocks will be attached once the cables pass through the camera hole later.
  • Page 25 Hardware Manual 6. Insert the sealing insert and attach it at the end of the flex conduit. 7. Insert the network cable and other cables (if any) through the camera conduit hole; pull enough cable length to connect to the camera. 8.

  • Page 26: Step 4: Connect To Network

    Hardware Manual 10. Connect other cables (if any) to their respective connectors. See Other Connections page 28 for detailed instructions. Step 4: Connect to Network Connect the other end of the network cable to a switch or injector. Then, connect the switch or injector to a network or PC and a power source.

  • Page 27: Step 6: Adjust The Viewing Angle

    Hardware Manual Step 6: Adjust the Viewing Angle Based on the live view, adjust the viewing angle and orientation of the camera. 1. Loosen the pan adjustment screw, then turn the lens module to pan the camera. 2. Tighten the pan adjustment screw to fix its pan position. Pan Adjustment Screw Tilt Adjustment Screw NOTE:...

  • Page 28: Other Connections

    Hardware Manual Other Connections This section describes the procedures in preparing an external power adapter or other input and output devices, such as digital or alarm, audio and video that you can connect to the camera. The use of these devices, however, is optional. Connecting a Power Adapter (Optional) The camera can be powered by a Power over Ethernet (PoE) switch that is IEEE802.3af compliant.

  • Page 29: Connecting Input / Output Devices (Optional)

    Hardware Manual Connecting Input / Output Devices (Optional) Depending on your surveillance needs, you may connect digital input / output, audio input / output, and video output device to your camera. How to Connect DI/DO Devices To connect digital input / output devices (DI/DO), map the pins to one of the pin combinations below: Device Mapping Instructions...

  • Page 30: How To Connect Audio Input / Output Devices

    Hardware Manual NOTE: For more information on DI/DO connections, please refer to the Knowledge Base article downloadable from the website. How to Connect Audio Input / Output Devices Audio input and output devices, such as a microphone and speaker, can be connected to the camera.

  • Page 31: How To Connect A Video Output Device

    Hardware Manual How to Connect a Video Output Device A video output device, such as the Camera Installation Kit, can be connected to the camera to see the live view during installation through the Camera Installation Kit BNC connection. To connect the video output device, map the pins of the BNC cable as follows: Device Mapping Instructions Connect the wires of the video output device to VO and...

  • Page 32: Other Accessories

    Hardware Manual Other Accessories How to Install / Remove the Memory Card The camera supports local video recording to a memory card. NOTE: Supports microSDHC and microSDXC cards. How to Insert the Memory Card Insert a memory card into the card slot with the metallic contacts facing the “MicroSD” label on the camera.

  • Page 33: How To Attach The Rj-45 Connector

    Hardware Manual How to Attach the RJ-45 Connector 1. Prepare the following tools: a. RJ-45 connector b. Crimping tool c. Scissors 2. Cut about one (1) inch into the plastic sheath from the end of the cable. 3. Unwind the wires and arrange them according to the color sequence below. Stripe Orange Orange Stripe Green...
  • Page 34 Hardware Manual 5. With the RJ-45 connector tab facing down, push down the wires into the connector all the way to the end. 6. Place the connector into the crimping tool, and cinch down to secure the RJ-45 connector to the Ethernet cable.

  • Page 35: Accessing The Camera

    Hardware Manual Accessing the Camera Configure the IP Addresses In order to be able to communicate with the camera from your PC, both the camera and the PC have to be within the same network segment. In most cases, it means that they both should have very similar IP addresses, where only the last number of the IP address is different from each other.
  • Page 36 Hardware Manual If you work with our cameras regularly, then there is even a better way to discover the cameras in the network – by using IP Utility. The IP Utility is a light software tool that can not only discover the cameras, but also list lots of valuable information, such as IP and MAC addresses, serial numbers, firmware versions, etc, and allows quick configuration of multiple devices at the same time.
  • Page 37 Hardware Manual Use the default IP address of a camera: If there is no DHCP server in the given network, the user may have to assign the IP addresses to both PC and camera manually to make sure they are in the same network segment. When the camera is plugged into network and it does not detect any DHCP services, it will automatically assign itself a default IP: 192.168.0.100...
  • Page 38 Hardware Manual Manually adjust the IP addresses of multiple cameras: If there are more than 1 camera to be used in the same local area network and there is no DHCP server to assign unique IP addresses to each of them, all of the cameras would then have the initial IP address of 192.168.0.100, which is not a proper situation for network devices –...

  • Page 39: Access The Camera

    Hardware Manual Access the Camera Now that the camera and the PC are both having their unique IP addresses and are under the same network segment, it is possible to use the Web browser of the PC to access the camera. Full functionality is provided only for Microsoft Internet Explorer.
  • Page 40 Hardware Manual Upon successful connection to the camera, the user interface called Web Configurator would appear together with the login page. The HTTP port number was not added behind the IP address since the default HTTP port of the camera is 80, which can be omitted from the address for convenience.
