- Page 1 4P359542-3S Installation Manual Wireless LAN Connecting Adapter <BRP069A45>...
- Page 3 Hereby, Daikin Industries Czech Republic s.r.o. declares that the radio equipment type BRP069A41 is in compliance with Directive 2014/53/EU. Accessories Check if the following accessories are included in your package.
-
Page 4: Safety Precautions
Safety precautions The following describes the meanings of pictorial symbols used in this documentation. Give this installation manual to the customer when installation is completed. To conduct a test run of the air conditioner, follow the installation manual for the air conditioner unit. - Page 5 Safety precautions Warning Situations which could result in death or serious injury. When using: Do not disassemble, modify, or repair. (Can cause fire, electric shock or injury.) Do not handle this product with wet hands. (Can cause electric shock or fire.) ...
-
Page 6: When Using
Safety precautions Caution Situations which could result in damage or physical injury. When installing: Do not install where flammable gas leaks can occur. (Can cause fire.) Grip the connector when disconnecting the connecting cord. (Otherwise fire or electric shock can occur.) When using: ... -
Page 7: Disposal Requirements
Disposal requirements Your product is marked with this symbol. This symbol means that electrical and electronic products shall not be mixed with unsorted household waste. Do not try to dismantle the system yourself: the dismantling of the product and of other parts must be done by a qualifi... - Page 8 Main components Basic parameters: Frequency range: 2400 MHz–2483.5 MHz Radio protocol: IEEE 802.11b/g/n RF channel: 1–13 Output power: 0 dBm~18 dBm ERP: 17 dBm (11b) / 13 dBm (11g) / 12 dBm (11n) Power supply: DC 14 V / 100 mA RF channel: Radio frequency channel ERP: Effective radiated power Applicable indoor unit...
-
Page 9: Installation
Installation Installation Work Attach the Wireless LAN connection adapter to indoor unit. Danger ■ BRP069A41 Always turn off the power supply when installing. (Touching the electrical parts can cause Refer to your air conditioner‘s an electric shock.) The main switch of the installation is at the outdoor unit. - Page 10 Installation Installation Work Remove the adapter case (upper). ■ BRP069A41 Press a regular screwdriver into the dent between the upper and lower cases to remove. (Be careful not to damage the case.) Regular screwdriver Adapter case (upper) Wireless LAN Adapter connecting adapter case (lower) printed circuit board...
- Page 11 Installation Installation Work Attach connecting cord to the product. ■ BRP069A41 Attach the connecting cord connector (white). Fasten the connecting cord to the notch in the adapter case (lower). Connect the connector to the same color. Connector (white) Fasten the connecting cord and ensure that external force is not transmitted.
- Page 12 Installation Installation Work Return the adapter case to its original state. ■ BRP069A41 Snap the top of the upper case unto the clip at the top of the lower case and press to close the box. Adapter case Adapter case (lower) top (upper) top portion clip...
- Page 13 Installation Installation Work Class 15-35 • Place the wireless adapter against the hooks (1). • Lock the adapter by pressing it down (2). Class 50-71 • Place the wireless adapter into the holder (1). • Fix the adapter in the holder by pressing down on it (2). English 11...
-
Page 14: Functionality Check
Installation Installation Work Functionality Check ■ BRP069A41 Turn on the power supply and check that the [POWER] lamp for the product lights.. When turning on the power, always attach the adapter case (top). English 12... - Page 15 (Supported OS: Android 2.3.3 or later; iOS 5.0 or later.) □ Internet line and communicating device (Modem/router or similar device) □ Wireless LAN access point □ [Daikin online controller] (No cost) Installation method of Daikin online controller For Android Phones For iPhones (1) Open the [Google Play].
-
Page 16: Troubleshooting
Troubleshooting The following table provides brief descriptions of how to handle trouble or uncertainties when you install the product or make connection settings. Refer to the FAQ on the homepage for more details. When this happens Explanation and where to check None of the LEDs light →... - Page 17 Troubleshooting When this happens Explanation and where to check When trying to make → If the AP LED is not lit, press the a direct connection to "Mode" button for 2 seconds to the adapter (AP mode) switch to AP mode. the WLAN adapter is not →...
- Page 19 4P359542-3S 2017.05...
